Processors

Memory

Supports 16 2933 MT/s DDR4 DIMMs, up to 1 TB memory capacity (configured with 64 GB DIMMs)

Supports 4 2666 MT/s DCPMMs as volatile or non-volatile storage, which can be used together with 8 DDR4 DIMMs, offering up to 2.5 TB memory capacity (configured with 512 GB DCPMMs and 64 GB DDR4 DIMMs)

Internal Storage

Up to 6 x 2.5-inch SAS/SATA/SSD/NVMe drives or 3 x 3.5-inch SAS/SATA/SSD drives
Up to 2 x M.2 2280 or 2242 SATA SSDs
Support for mixed use of different drive types

RAID Support

RAID 0, 1, 5, 6, 10, 50, or 60; supercapacitor for power failure protection
M.2 SSDs can be used to build RAID 0 or 1

LOM Network Ports

2 x GE + 2 x 10 GE

PCIe Expansion

2 PCIe x16 half-height, half-length standard expansion slots

Management

Supports standard management interfaces such as SNMP and IPMI
Provides management features such as virtual KVM, virtual media, SOL, remote control, hardware monitoring, and intelligent power supply
Supports power capping, independent management network port, and NC-SI management

Operating Systems

Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, CentOS, Citrix XenServer, and VMware ESXi

Operating Temperature

5ºC to 35ºC

Certification

CE, UL, FCC, CCC, VCCI, and RoHS

Dimensions (H x W x D)

40.5 mm x 177.9 mm x 545.5 mm
