02310RHT Huawei Storage Server

02310RHT Huawei Storage Server

  • 02310RHT Huawei Storage Server
02310RHT Huawei Storage Server
Product Details:
Place of Origin: China
Brand Name: Huawei
Certification: CE FCC RoHS
Model Number: RH1288 V2
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Export carton package
Delivery Time: 7-15 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 200 Piece/Pieces per Week
Contact Now
Detailed Product Description
Type: Rack Max Memory Capacity: >= 64GB
Max Processors: 2 Processor Main Frequency: 3.3GHz
Processor Type: Xeon Core Options: 4, 6, 8,10 Or 12
Maximum Power: 135 W L3 Cache: 30 MB
High Light:

02310RHT Huawei Storage Server


02310RHT Huawei Server



02310RHT server RH1288 V2 power module BC1M02PSUA FOR HUAWEI

More Items:

BC1M01PSUA00 460W platinum AC power supply module

BC1MACPSUA00 750W AC Gold Power Module

BC1M04PSUA 750W AC platinum power supply module

The HUAWEI RH1288 V2 (RH1288 V2 for short) is a new-generation 1U rack server. With an optimized architecture, it supports two Intel® Xeon® E5-2600 series processors, a maximum memory capacity of 768 GB, and an internal storage capacity of 12 TB, providing high performance while achieving high density. It is an ideal choice for enterprise intensive applications and cloud computing.

Model Number
Intel® Xeon® E5-2600/E5-2600 V2 (Romely-EP) series
Core options: 4, 6, 8,10 or 12
Maximum power: 135 W
Maximum dominant frequency: 3.3 GHz
L3 cache: 30 MB
Number of processors
1 or 2
24 DDR3 RDIMMs/LRDIMMs, up to 768 GB
Internal storage
8 x 2.5" SAS/SATA HDDs or SSDs, up to 8 TB
4 x 3.5" SAS/SATA hard disks, up to 12 TB
RAID support
RAID 0, 1, 10, 5, 50, 6, and 60
RAID cache: 512 MB or 1 GB
Power-off protection:
Super capacitor
LOM network port
2 or 4 onboard GE ports or 2 onboard 10GE ports
Power supply
110 V/220 V AC or –48 V DC
Dimensions (H x W x D)
Height: 43.6 mm (1.72 in.)
Width: 447 mm (17.60 in.)
Depth: 740 mm (29.13 in.)


1.  Excellent Performance and Flexible Scalability
1)Supports Intel® Xeon® E5-2600 / E5-2600 V2 series processors, providing a maximum L3 cache of 30 MB and QuickPath Interconnect (QPI) at 8 GT/s.
2). Supports the intelligent power consumption management and Intel Turbo Boost Technology, providing high performance while reducing power consumption.
3)Meets requirements for memory-intensive applications by providing 24 DDR3 DIMM slots and up to 768 GB memory capacity.
4)Supports flexible configuration and high network I/O performance by providing onboard two GE or four GE or two 10GE ports.

2.  High Energy Efficiency
1)Uses highly efficient 80 Plus Platinum PSUs that comply with the ENERGY STAR standards and have passed the China Energy Conservation and Environmentally-Friendly Certification.
2)Provides 460 W, 750 W, and 800 W PSUs for flexible configurations to improve power efficiency.
3)Uses temperature sensors to monitor the heat of key components, working with intelligent fan speed adjustment to precisely cool the server, markedly increasing the cooling efficiency.
4)Adopts dynamic power saving and power capping to control the preset power consumption, preventing service interruption.

3.  Simple Management and Maintenance
1)Supports the black box function to facilitate quick fault location and service recovery.
2)Implements simple system management by using the built-in BMC, which supports SOL and remote KVM, startup, and shutdown.
