02310MKT Huawei Storage Server

02310MKT Huawei Storage Server

  • 02310MKT Huawei Storage Server
02310MKT Huawei Storage Server
Product Details:
Place of Origin: China
Brand Name: Huawei
Certification: CE FCC RoHS
Model Number: RH2288H V2
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Export carton package
Delivery Time: 7-15 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 200 Piece/Pieces per Week
Contact Now
Detailed Product Description
Type: Rack Max Memory Capacity: >= 64GB
Max Processors: 2 Processor Main Frequency: 3.3GHz
Processor Type: Xeon RAID: 0,1,10,5,50,6,60
High Light:

02310MKT Huawei Storage Server


02310MKT Huawei Server


02310MKT Storage Server

02310MKT server Tecal RH2288H V2 Universal Hard Disk BC1MSRSCR814


More Items :

BC1HDD36 02310UGB General-purpose hard disk -4000GB-NL-SAS 6Gb / s-7200rpm-3.5inch-64MB and above-Hot-Plug-built-in -3.5-inch handle

BC1MSRSCR803 02310LBB Universal Hard Disk - 500GB-SATA-7200rpm-2.5 "-64M- Hot Swap - Built-In - Handle

BC1MSRSCR804 02310LAY Universal Hard Disk - 1000GB-SATA-7200rpm-2.5 "-64M-Hot Swap-Built-In-Handle

BC1MSRSCR821 02310MMV General-purpose hard disk-300GB-SAS 6Gb / s-15000rpm-2.5 "-64M-Hot Swap-Built-in-handle

N0SASHD06 02310KPR Universal hard disk -300GB-SAS-10000rpm-2.5 "-16M-hot swap - built-in - handle


Huawei Tecal RH2288H V2 is Huawei's next-generation 2U dual-rack server supporting two Intel® Xeon® E5-2600 / E5-2600V2 series processors. With the efficient design, the maximum configuration is 768GB of memory and high-capacity local storage. Optimal computing performance and scalability are ideal for mission-critical applications and cloud computing.

Model Number
Intel® Xeon® E5-2600/E5-2600 V2 series
Number of processors
1 or 2
24 DIMM sockets, support DDR3 RDIMM / LRDIMM memory, maximum support 768GB
Internal storage
8 x 2.5''  SAS / SATA / SSD
12  x 3.5''  SAS / SATA and 2 x 2.5'' SAS / SATA / SSD
26  x 2.5''  SAS / SATA / SSD
RAID support
RAID 0, 1, 10, 5, 50, 6, and 60
LOM network port
2 GE ports or 4 GE ports or 2 10GE Ethernet ports
Power supply
2 hot-swappable 460W / 800W AC power or 800W -48V DC power supply, support 1 +1 redundancy


1.Performance is strong
1) RH2288H V2 [1] uses the latest Intel® Xeon® E5-2600 / E5-2600V2 series processors with up to 12 cores per core, 30M L3 cache, 8GT / sec QPI (QuickPath Interconnect), Smart Power Regulation, to achieve the perfect combination of performance, power consumption, support Hyper-Threading, Turbo acceleration technology;
2)Support 24 RDIMM memory, memory capacity of the largest 768GB, to meet a variety of memory-intensive applications;
3)Optional Huawei ES series PCIe SSD high-performance memory card, providing far more than the traditional hard disk I / O performance, to solve disk performance bottlenecks.

2. Low energy consumption
1)80PLUS ® platinum energy-efficient power supply module to meet the Energy Star standards, and through China's energy-saving environmental protection product certification;
2)Can be selected on demand 460W, 800W and other power modules, improve energy efficiency;
3)The internal key parts of the temperature sensor, real-time monitoring of temperature in different regions of the situation, combined with intelligent fan speed control technology for accurate cooling, improve system cooling efficiency;
4)Dynamic power capping governs the power consumption of servers that are preconfigured to prevent excessive power consumption, and does not affect business operations.

3.Management convenience
1)Provide similar "black box" fault information record, you can quickly locate the cause of unexpected downtime, quickly resume business operations;
2)Independent BMC management module provides SOL, remote KVM, remote switching machine and other rich management functions, to achieve convenient and safe system management.

4.Storage configuration
1)Three 2.5 "SAS / SATA / SSD hard drives, 12 3.5" SAS / SATA + 2 2.5 "SAS / SATA / SSD hard drives or" 24 + 2 "hard drives are available in three storage configurations, "2.5-inch SAS / SATA / SSD hard drive three options available;
2)Support for industry-leading RAID technology, support RAID0,1,10,5,50,6,60, etc., to provide 512M / 1GB Cache, to support Cache battery protection and super capacitor protection, support for RAID state migration, RAID configuration memory and other functions, Diagnosis, WEB remote settings and other functions to protect data reliability.
