Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | SSN1MD12 |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| Type: | Fiber Identifier | SSN1MD12: | Multi-protocol 32-channels E1 Interface Processing Board |
|---|
The MD12 receives and transmits 32xE1 signals and works with the PEG8 to process E1 CES and ATM/IMA services.
Table 1 provides the functions and features of the MD12.
| Function and Feature | MD12 | |
|---|---|---|
| Basic functions | Transmits and receives 32xE1 signals, and works with the PEG8 to process E1 CES and ATM/IMA services. | |
| Interface types | Supports 120-ohm E1 electrical interface. The electrical interface uses the DB44 connector. | |
| Interface characteristics | Loopback types of the port | Inloop Outloop Non-loopback |
| Auto disabling of port loopback | Supported | |
| CES | Number of CES services | 32 |
| Emulation mode | CESoPSN, SAToP | |
| Jitter compensation buffering time | The jitter compensation buffering time of CES services can be set to a value in the range of 0.375 ms to 16 ms with a step of 0.125 ms. | |
| Packet loading time | The packet loading time of CES services can be set to a value in the range of 0.125 ms to 5 ms with a step of 0.125 ms. NOTE:
| |
| ATM/IMA | Number of IMA groups | 32 |
| Maximum number of E1 links in each IMA group | 16 | |
| Number of V-UNI ports | 512 | |
| Number of V-NNI ports | 128 | |
| Cell concatenation | Type:
| |
| Quantity: 31 | ||
| ATM OAM | Type:
| |
| Quantity: 512 | ||
| Service categories | CBR, UBR, UBR+, rt-VBR, nrt-VBR | |
| ATM QoS | Supported | |
| Clock function | Restores four CES adaptive clock recover (ACR) clocks. Clocks that are recovered from services over ports 1 and 9 can be added to the clock priority list. NOTE: Clock recovery over ports 1 to 16 is independent of clock recovery over ports 17 to 32. That is, clocks that are recovered from services over ports 1 to 16 can be transmitted out of ports 1 to 16 and clocks that are recovered from services over ports 17 to 32 can be transmitted out of ports 17 to 32. | |
| Clock mode | Line Clock Mode and Null. | |
| Line code of E1 link | HDB3 code | |
| Frame format of E1 link | Unframed format, double-framed format, or E1 CRC-4 multiframe format (default value) | |
| Maintenance features |
| |
The technical specifications of the MD12 include the specifications of electrical interfaces, mechanical specifications, and power consumption.
| Port type | Description |
|---|---|
| E1 electrical interfaces | 120 ohm E1 electrical interfaces |
The mechanical specifications of the MD12 are as follows:
The maximum power consumption of the MD12 at the room temperature (25°C) is 12 W.
