Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | SSN1PEFF8 |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| SSN1PEFF8: | 8-port Fast Ethernet Optical Interface Processing Board |
|---|
PEFF8 boards receive/transmit 8xFE optical signals and work with the PEG8 to process services.
Table 1 lists the functions and features supported by PEFF8 boards. When working with PEG8 boards, PEFF8 boards support the functions and features as described in Functions and Features.
| Function and Feature | Description | |
|---|---|---|
| Basic functions | Receives/Transmits and processes 8xFE optical signals. | |
| Port types | Supports 100Base-FX/LX/VX/ZX Ethernet optical ports. The optical ports use LC connectors and support the transmission distances of 2 km, 15 km, 40 km, and 80 km. | |
| Port characteristics | Pluggable optical module | Supports SFP optical modules. |
| Single-fiber bidirectional optical module | Supports SFP single-fiber bidirectional optical modules. | |
| Working modes | 100M full-duplex | |
| Flow control at ports | Auto-negotiation mode: not supported | |
| Non-autonegotiation mode: not supported | ||
| Query/Setting of port status | Supported | |
| Query of port types | Supported | |
| Query/Setting of optical power thresholds | Supported | |
| Query/Setting of unidirectional-mode | Not supported | |
| Service specifications | Service bearing modes | MPLS: supported |
| QinQ: supported | ||
| Port: supported | ||
| MFL for ports | Supports the setting of the packet length, which ranges from 960 bytes to 4600 bytes. After the setting becomes valid, the length of the packets that enter or exit the ports is restricted by the preset MFL. | |
| MTU for services | For packet services carried by PWs, PEFF8 boards support the setting of the packet length, which ranges from 64 bytes to 9600 bytes. For packet services carried in other modes, PEFF8 boards do not support the setting of the packet length. | |
| Ethernet service capability | E-Line service: supported | |
| E-LAN service: supported | ||
| E-AGGR service: not supported | ||
| Formats of Ethernet data frames | Supports the encapsulation in IEEE 802.3 format, Ethernet II format, or IEEE 802.1q/p format. | |
| Jumbo frame | Supports a jumbo frame with a length not more than 4600 bytes. | |
| MS-PW | Supports static MS-PWs. | |
| Protection schemes | Tunnel APS | Supports the 1+1 (single-ended/dual-ended) and 1:1 (dual-ended) MPLS Tunnel APS in compliance with ITU-T Y.1720 and ITU-T G.8131. |
| PW APS | Supports the PW FPS (single-ended), 1+1 (single-ended/dual-ended) and 1:1 (dual-ended) MPLS PW APS in compliance with ITU-T Y.1720 and ITU-T G.8131. | |
| MRPS | Supports MRPS.
| |
| LAG |
| |
| MC-LAG | Supported when working with a PEG8 board in compliance with 802.3ad and IEEE 802.1AX. | |
| MSTP | Supported, which complies with IEEE 802.1s. | |
| LPT | Point-to-point LPT: supported | |
| Point-to-multipoint LPT: supported | ||
| ETH-TRUNK | Supported | |
| Synchronization | Synchronous Ethernet Clock | Supports eight channels of synchronous Ethernet clock signals. |
| 1588v2 | Supports eight channels of IEEE 1588v2 time synchronization and clock synchronization. | |
| Maintenance features | ETH OAM | Ethernet Service OAMa: Supports CC, LB and LT. These functions comply with IEEE 802.1ag. Supports LM and 2DM. These functions comply with ITU-T Y.1731. |
| Ethernet Port OAMa: Supports OAM auto-discovery, fault detection, link performance monitoring, and selfloop test. These functions comply with IEEE 802.3ah. | ||
| Distributed MPLS OAM/Centralized MPLS OAM | MPLS tunnel OAMa: Supports CV, FFD, BDI, FDI, Tunnel ping, and Tunnel traceroute. These functions comply with ITU-T Y.1711. | |
| MPLS PW OAMa: Supports CV, FFD, BDI, FDI, PW traceroute, and PW ping. These functions comply with ITU-T Y.1711. | ||
| MPLS-TP OAM | MPLS-TP tunnel OAMa: Supports CC, RDI, AIS, LB, LT, LM, 1DM, TST, LCK, and 2DM. These functions comply with ITU-T G.8113.1. | |
| MPLS-TP PW OAMa: Supports CC, RDI, AIS, LB, LT, LM, 1DM, TST, LCK, CSF, and 2DM. These functions comply with ITU-T G.8113.1. | ||
| Loopback capability | PHY layer at Ethernet ports: supports inloops. | |
| MAC layer at Ethernet ports: supports inloops and outloops. | ||
| RMON | Supported | |
| Port Mirroring | Supported | |
| Inband DCN | Supported | |
| LLDP | Supported | |
| HQoS | Supports service WRED policies, port WRED policies, WFQ policies, PW polices, QinQ polices, V-UNI ingress policies, V-UNI egress policies, port policies, port shaping. | |
| IGMP Snooping | Protocol enabling | Supported |
| Port aging time | Supported | |
| Fast leave | Supported | |
| Discarding of unknown broadcast packets | Supported | |
| Static broadcast entry | Supported | |
| Query of electronic labels | Supported | |
| NOTE: a: MPLS tunnel OAM, MPLS PW OAM, MPLS-TP tunnel OAM, MPLS-TP PW OAM, and ETH OAM share OAM resources. | ||
The technical specifications of the PEFF8 include the specifications specified for optical interfaces, laser safety class, mechanical specifications, and power consumption.
Table 1 provides the specifications of the optical interfaces on the PEFF8.
| Port type | Description |
|---|---|
| 100BASE-FX | 2 km FE two-fiber bidirectional optical interfaces |
| 100BASE-LX | 15 km FE two-fiber bidirectional optical interfaces |
| 100BASE-VX | 40 km FE two-fiber bidirectional optical interfaces |
| 100BASE-ZX | 80 km FE two-fiber bidirectional optical interfaces |
| 100BASE-LX | 15 km FE single-fiber bidirectional optical interfaces |
| 100BASE-VX | 40 km FE single-fiber bidirectional optical interfaces |
The safety class of the laser on the board is Class 1. The maximum launched optical power of the optical interfaces is less than 10 dBm (10 mW).
The mechanical specifications of the PEFF8 are as follows:
The maximum power consumption of the PEFF8 at room temperature (25°C) is 12 W.
