| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | SSN6GSCC |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| Type: | Fiber Identifier | SSN6GSCC: | System Control And Communication Board |
|---|
The GSCC supports the system control, orderwire, communication, and system power supply monitoring.
Table 1 provides the functions and features of the GSCC.
| Function and Feature | GSCC |
|---|---|
| Basic functions | Performs the service configuration function and service grooming function, monitors the service performance, and collects information about performance events and alarms. |
| Interfaces |
|
| DCC communication | Processes a maximum of 160 DCCs (D1-D3). In this manner, the link is provided for transmitting the NM information. |
| Overhead processing | Processes the E1, E2, F1, and serial1-serial4 bytes. |
| Clock function |
|
| Alarms and maintenance features |
|
| Power supply management |
|
| Protection schemes | Supports the 1+1 Hot Backup for the SCC Unit. When the active board is faulty, services are switched to the standby board automatically. NOTE: If GSCC boards are used in packet systems, two N4GSCC/N6GSCC boards of the same version need to be configured in 1+1 backup mode. |
| Packet function | The N4GSCC and N6GSCC support the packet function. For information about the performance of the packet system, see Packet System Performance. |
The technical specifications of the GSCC include the mechanical specifications and power consumption.
The mechanical specifications of the GSCC are as follows:
The maximum power consumption of the GSCC at room temperature (25°C) is 19 W.
