| SST2PSXCSA: | Super Dual-plane Cross-connect And Timing Board | Port: | Shenzhen |
|---|
The PSXCSA board grooms services and inputs/outputs clock signals.
Table 1 provides the functions and features supported by the cross-connect unit of the PSXCSA board.
| Function and Feature | Description | ||||
|---|---|---|---|---|---|
| Basic functions | Cross-connect capacity | T1PSXCS | T2PSXCSA | ||
| Higher order cross-connect capacity (Gbit/s) | 360 | 360 | |||
| Lower order cross-connect capacity (Gbit/s) | 40 | 40 | |||
| Packet switching capacity (Gbit/s) | 160 | 120 | |||
| Service access capacity | TDM mode (Gbit/s) | 320 | 320 | ||
| Packet mode (Gbit/s) | 160 | 120 | |||
| Service processing |
| ||||
| Protection scheme | Supports 1+1 hot standby. The default reversion mode is the non-revertive switching mode. | ||||
| Others | Queries and reports the working temperature of the cross-connect and timing board and the entire equipment. | ||||
Table 2 provides the functions and features supported by the clock unit of the PSXCSA board.
| Function and Feature | Description |
|---|---|
| Basic functions | Provides the standard clock for system synchronization. |
| Other functions |
|
| Input and output | Working with the AUX and EOW boards:
|
The technical specifications of the PSXCSA include the mechanical specifications, and power consumption.
The mechanical specifications of the PSXCSA are as follows:
The mechanical specifications of the PSXCSA are as follows:
The maximum power consumption of the T1PSXCSA/T2PSXCSA at room temperature (25°C) is 87 W.
