Port Specifications

Supported Wavelengths

HSNS3 boards support the following wavelengths:

• 1271 nm, 1291 nm, 1311 nm, and 1331 nm when the transmission distance is 10 km or 40 km
• 1531.12 nm, 1537.4 nm, 1543.73 nm, and 1550.12 nm when the transmission distance is 80 km

Laser Hazard Level

The laser hazard level of the optical port on an HSNS3 board is CLASS 1. That is, the maximum launched optical power of the optical port is lower than 10 dBm (10 mW).

Mechanical Specifications

The mechanical specifications of HSNS3 boards are as follows:

• Dimensions (H x W x D): 261.4 mm x 50.3 mm x 235.2 mm
• Weight: 2.3 kg

Power Consumption

The maximum power consumption of an HSNS3 board at room temperature (25ºC) is 55 W.

Notice:

Above mentioned information are just for your reference only,we will keep you posted for the tracking delivery schedule.There are two delivery options available for by air and by sea:

Deliver to port:

Uonel is responsible for transporting goods to port. All subsequent customs and transportation fees are the
responsibility of the buyer. Uonel will recommend trustworthy local freight forwarders to you.Uonel can facilitate the progress under buyer's permission and at buyer's expense.

Deliver to door:

Uonel will quote all destination charge prior once we have confirmed order.
Uonel is responsible for transporting goods to door after you have made the payment.

Standard Hardware Warranty Policy:

Original new sealed  product: 1 Year

The Support Contacts:

If your  products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.
