Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | SS42SHLQ |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| Type: | Fiber Identifier | SS42SHLQ: | 4 X Single Pair High-Bit-Rate Digital Subscriber Line Interface Board |
|---|
The SHLQ converts four G.SHDSL signals into four standard E1 signals, maps the E1 signals into VC-4s, and sends the VC-4 signals to the cross-connect unit. The SHLQ also processes path overheads and generates alarm signals on the tributary.
Table 1 provides the functions and features of the SHLQ.
| Function and Feature | SHLQ |
|---|---|
| Basic functions | Provides four G.SHDSL interfaces, supports cabling from the front panel, and uses RJ-11 connectors to connect copper twisted pairs. The interfaces use two-wire cables. |
| Long-distance transmission | Transmits E1 and Nx64 kbit/s data services in the G.SHDSL format, thus realizing long-distance access of E1 and Nx64 kbit/s signals. |
| Overhead processing | Processes path overheads, configures all G.SHDSL service paths, monitors alarms and performance events on the service paths, and enables the communication between the service paths and the SCC unit. |
| Clock source | Provides one synchronous clock source. |
| Protection modes | Supports the SNCP switching and bit error protection switching. |
The technical specifications of the SHLQ include the parameters specified for electrical interfaces, dimensions, weight, and power consumption.
Table 1 lists the parameters specified for the electrical interfaces of the SHLQ.
| Parameter | Value |
|---|---|
| Nominal bit rate | Nx64 kbit/s and Framed E1 |
| Connector type | RJ-11 connector, two-wire twisted pair |
| Maximum transmission distance (km) | 3 |
The mechanical specifications of the SHLQ are as follows:
The maximum power consumption of the SHLQ at room temperature (25°C) is 10.0 W.
