Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | SS42FP2D |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| Type: | Fiber Identifier | SS42FP2D: | 16 X Framed E1 Interface Board |
|---|
The N64/N64Q/FP2D accesses Nx64 kbit/s services and Framed E1 services.
The N64/N64Q is an Nx64 kbit/s interface board.
The N64/N64Q transmits, receives, and processes multi-protocol physical interface services.
The N64 can convert two V.35/V.24/X.21/RS-449/EIA-530 signals and two Framed E1 signals into E1 signals at the same time, map the E1 signals into VC-4s, and send the VC-4 signals to the cross-connect unit. The N64 can also consolidate Framed E1 services and Nx64 kbit/s services, and extract timeslots.
The N64Q can convert four V.35/V.24/X.21/RS-449/EIA-530 signals into E1 signals, map the E1 signals into VC-4s, and send the VC-4 signals to the cross-connect unit. The N64Q supports timeslot cross-connection, consolidation of E1 services and Nx64 kbit/s services, and timeslot extraction. The N64Q also supports Nx2.4 kbit/s subrates, where N is equal to or less than 18.
The FP2D can access Framed E1 services.
Table 1 provides the functions and features of the N64/N64Q/FP2D.
| Function and Feature | N64/N64Q/FP2D |
|---|---|
| Basic functions |
|
| Overhead processing | Processes path overheads, configures 2 Mbit/s or Nx64 kbit/s service paths, monitors alarms and performance events on the service paths, and communicates with the SCC unit. |
| Protection modes | Supports automatic protection switching. The FP2D supports the PPS protection. |
| Maintenance features |
|
| Alarms and performance events | Provides rich alarms and performance events, thus facilitating the management and maintenance of the equipment. |
The technical specifications of the N64/N64Q/FP2D include the parameters specified for electrical interfaces, dimensions, weight, and power consumption.
Table 1 lists the parameters specified for the electrical interfaces of the N64/N64Q/FP2D.
| Parameter | Value |
|---|---|
| Nominal bit rate | Nx64 kbit/s |
| Interface type | N64: V.35, X.21, RS-449, V.24, EIA-530, and Framed E1 N64Q: V.35, X.21, RS-449, V.24, and EIA-530 |
| Standard compliance | ITU-T V.35, ITU-T V.28, ITU-T V.24, EIA-530, EIA-449, EIA-232, ITU-T G.703, ITU-T G.704, and ITU-T G.706 |
| Connector type | N64/N64Q: 2 mm HM connector FP2D: DB78 |
The mechanical specifications of the N64 are as follows:
The mechanical specifications of the N64Q are as follows:
The mechanical specifications of the FP2D are as follows:
