Parameters Specified for Electrical Interfaces

Table 1 lists the parameters specified for the electrical interfaces of the EFS/EFSC/EFS4.

Parameters Specified for Optical Interfaces

Table 2 lists the parameters specified for the optical interfaces of the EGS.

Mechanical Specifications

The mechanical specifications of the EFS are as follows:

• Dimensions (width x depth x height): 89.0 mm x 218.5 mm x 24.0 mm
• Weight: 0.26 kg

The mechanical specifications of the EFS4 are as follows:

• Dimensions (width x depth x height): 89.0 mm x 218.5 mm x 24.0 mm
• Weight: 0.25 kg

The mechanical specifications of the EGS are as follows:

• Dimensions (width x depth x height): 89.0 mm x 218.5 mm x 24.0 mm
• Weight: 0.3 kg

The mechanical specifications of the EFSC are as follows:

• Dimensions (width x depth x height): 321.0 mm x 218.5 mm x 24.0 mm
• Weight: 0.6 kg

Power Consumption

• The maximum power consumption of the EFS at room temperature (25°C) is 23 W.

• The maximum power consumption of the EFS4 at room temperature (25°C) is 15 W.
• The maximum power consumption of the EFSC at room temperature (25°C) is 22 W.
• The maximum power consumption of the EGS at room temperature (25°C) is 25 W.
