Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | SS42PE3T |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| Type: | Fiber Identifier | SS42PE3T: | 3xE3 Electrical Interface Board |
|---|
The PE3S/PE3D/PE3T/PT3S/PT3D/PT3T transmits and receives E3/T3 electrical signals, processes VC-3 path overheads, and generates alarm signals on the tributary.
Table 1 provides the functions and features of the PE3S/PE3D/PE3T/PT3S/PT3D/PT3T.
| Function and Feature | PE3S | PE3D | PE3T | PT3S | PT3D | PT3T |
|---|---|---|---|---|---|---|
| Basic functions |
| |||||
| Mapping processing | Maps E3 or T3 signals into a VC-4 signal by using the asynchronous mapping and multiplexing method. | |||||
| Overhead processing | Processes the path overheads at the VC-3 level. Supports the setting and querying of overhead bytes such as the J1 and C2. | |||||
| Alarms and performance events | Provides rich alarms and performance events, thus facilitating the management and maintenance of the equipment. Supports the alarm reversion function. | |||||
| Clock source | The PE3S/PT3S provides one reference clock source. The PE3D/PT3D/PE3T/PT3T provides two reference clock sources. | |||||
| Protection modes | Supports the SNCP, with a switching time of less than 50 ms. | |||||
| Maintenance features |
| |||||
The technical specifications of the PE3S/PE3D/PE3T/PT3S/PT3D/PT3T include the parameters specified for electrical interfaces, dimensions, weight, and power consumption.
Table 1 lists the parameters specified for the electrical interfaces of the PE3S/PE3D/PE3T/PT3S/PT3D/PT3T.
| Parameter | Value |
|---|---|
| Nominal bit rate | 34368 kbit/s, 44736 kbit/s |
| Interface impedance | 75 ohms |
| Line code pattern | T3: B8ZS E3: HDB3 |
| Connector | SMB coaxial connector |
| Signal bit rate at the output interface | Complies with ITU-T G.703. |
| Allowed frequency deviation at the input interface | |
| Allowed attenuation at the input interface | |
| Input jitter tolerance | T3: Complies with ITU-T G.824. E3: Complies with ITU-T G.823. |
The mechanical specifications of the PE3S/PE3D/PE3T/PT3S/PT3D/PT3T are as follows:
The maximum power consumption of the PE3S/PE3D/PE3T/PT3S/PT3D/PT3T at room temperature (25°C) is 7.0 W.
