Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | SS42SM1S |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| Type: | Fiber Identifier | SS42SM1S: | 4xE1/T1 Electrical Interface Board |
|---|
The SM1S/SM1D/PM2S/PM2D/PM2T transmits and receives E1/T1 electrical signals, processes VC-12 path overheads, and generates alarm signals on the tributary.
Table 1 provides the functions and features of the SM1S/SM1D/PM2S/PM2D/PM2T.
| Function and Feature | SM1S | SM1D | PM2S | PM2D | PM2T |
|---|---|---|---|---|---|
| Basic functions |
| ||||
| Mapping processing | Realizes the mapping and demapping between the E1 and the VC-4. | ||||
| Overhead processing | Processes the path overheads at the VC-12 level. Supports the setting and querying of overhead bytes such as the J2 and V5. | ||||
| Alarms and performance events | Provides rich alarms and performance events, thus facilitating the management and maintenance of the equipment. Supports the alarm reversion function. | ||||
| Clock source |
| ||||
| Protection modes | Supports the SNCP, with a switching time of less than 50 ms. | ||||
| Maintenance features |
| ||||
The technical specifications of the SM1S/SM1D/PM2S/PM2D/PM2T include the parameters specified for electrical interfaces, dimensions, weight, and power consumption.
Table 1 lists the parameters specified for the electrical interfaces of the SM1S/SM1D/PM2S/PM2D/PM2T.
| Parameter | Value |
|---|---|
| Nominal bit rate | 1544 kbit/s, 2048 kbit/s |
| Interface impedance | 100/120 ohms and 75 ohms |
| Line code pattern | T1: B8ZS E1: HDB3 |
| Connector | 2 mm HM connector |
| Signal bit rate at the output interface | Complies with ITU-T G.703. |
| Allowed frequency deviation at the input interface | |
| Allowed attenuation at the input interface | |
| Input jitter tolerance | T1: Complies with ITU-T G.824. E1: Complies with ITU-T G.823. |
The mechanical specifications of the SM1S are as follows:
The mechanical specifications of the SM1D are as follows:
The mechanical specifications of the PM2S are as follows:
The mechanical specifications of the PM2D are as follows:
The mechanical specifications of the PM2T are as follows:
The maximum power consumption of the SM1S at room temperature (25°C) is 4 W.
The maximum power consumption of the PM2S at room temperature (25°C) is 9 W.
The maximum power consumption of the PM2T at room temperature (25°C) is 11 W.
