Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | SS42SL1Q03 |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| Type: | Fiber Identifier | SS42SL1Q03: | L.1.1 |
|---|
The OI2S, OI2D, SL1Q, and SL1O boards access STM-1 signals.
Accesses STM-1 optical signals.
Provides four types of optical interfaces: Ie-1, S-1.1, L-1.1 and L-1.2.
The OI2S and OI2D boards can provide the synchronous clock source for the clock unit.
Supports MSP and SNCP.
Supports the ALS function.
Provides DCCs and orderwire communication.
Supports inloop and outloop.
The OI2S and OI2D boards supports the pluggable optical module.
Table 1 lists the functions of the OI2S, OI2D, SL1Q, and SL1O boards.
| Item | OI2S | OI2D | SL1Q | SL1O |
|---|---|---|---|---|
| Number of interfaces | 1xSTM-1 | 2xSTM-1 | 4xSTM-1 | 8xSTM-1 |
| Optical interface type | Ie-1, S-1.1, L-1.1, and L-1.2 | |||
| Valid slot | IU1, IU2, and IU3 | IU1, IU2, IU3, and IU5a | IU4 | IU4 |
| Type of connector | SC/LC | SC/LC | SC | SC |
| Number of synchronous clock sources | 1 | 2 | - | - |
| DCC communication | D1-D3 and D4-D12 | D1-D3 and D4-D12 | D1-D3 | D1-D3 |
| a: The IU5 is a logical slot that is integrated on the SCB board. | ||||
When the OptiX 155/622H uses the STM-1 optical interface board, the equipment can implement the following functions:
Forms rings or chains operating at the STM-1 rate.
Forms rings or chains operating at the STM-1 rate with other equipment, such as the OptiX 155/622 and the OptiX 2500+.
Provides STM-1 interfaces for interconnection with third-party equipment.
The SL1Q and SL1O boards do not support MSP but support SNCP. The SL1Q and SL1O boards are mainly connected to the low-level transmission equipment, such as the OptiX Metro 500 and the OptiX Metro 100.
