Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | SSN1DCU |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| SSN1DCU: | Dispersion Compensation Board | Port: | Shenzhen |
|---|
The DCU can compensate for the dispersion for a maximum of two channels of optical signals. The DCU can be used with the BA and PA.
Table 1 provides the functions and features of the DCU.
| Function and Feature | N1DCU | N2DCU |
|---|---|---|
| Basic functions | Compensates for the dispersion of a maximum of two channels of optical signals at the same time. Supports the compensated dispersion of 1020 ps/nm (for the dispersion caused by the 60 km G.652 optical fiber), 1360 ps/nm (for the dispersion caused by the 80 km G.652 optical fiber), or any combination. | Compensates for the dispersion of a maximum of two channels of optical signals at the same time. Supports the compensated dispersion of 680 ps/nm (for the dispersion caused by the 40 km G.652 optical fiber), 1020 ps/nm (for the dispersion caused by the 60 km G.652 optical fiber), 1360 ps/nm (for the dispersion caused by the 80 km G.652 optical fiber), or any combination. |
| Dispersion compensation method | Compensates for the dispersion accumulated during the transmission by using the chirp grating and suppresses the pulse signals to restore the optical signals. | |
| Long haul transmission with optical regeneration | Realizes long haul transmission with optical regeneration when working with the BA and PA. | |
The number code that follows the board name in the bar code is the feature code of the board. The feature code of the DCU indicates the compensated dispersion for the optical signals.
Table 1 provides the relationship between the feature code of the DCU and the compensated dispersion.
| Board | Feature Code | Compensated Dispersion |
|---|---|---|
| SSN1DCU01 | 01 | Compensated dispersion for a single channel: 60 km |
| SSN1DCU02 | 02 | Compensated dispersion for a single channel: 80 km |
| SSN1DCU03 | 03 | Compensated dispersion for dual channels: 60 km/60 km |
| SSN1DCU04 | 04 | Compensated dispersion for dual channels: 80 km/80 km |
| SSN1DCU05 | 05 | Compensated dispersion for dual channels: 60 km/80 km |
| SSN2DCU01 | 01 | Compensated dispersion for a single channel: 40 km |
| SSN2DCU02 | 02 | Compensated dispersion for a single channel: 60 km |
| SSN2DCU03 | 03 | Compensated dispersion for a single channel: 80 km |
| SSN2DCU04 | 04 | Compensated dispersion for dual channels: 40 km/40 km |
| SSN2DCU05 | 05 | Compensated dispersion for dual channels: 60 km/60 km |
| SSN2DCU06 | 06 | Compensated dispersion for dual channels: 80 km/80 km |
| SSN2DCU07 | 07 | Compensated dispersion for dual channels: 40 km/60 km |
| SSN2DCU08 | 08 | Compensated dispersion for dual channels: 40 km/80 km |
| SSN2DCU09 | 09 | Compensated dispersion for dual channels: 60 km/80 km |
The technical specifications of the DCU include the parameters specified for optical interfaces, mechanical specifications, and power consumption.
Table 1 lists the parameters specified for the optical interfaces of the DCU.
| Parameter | Value |
|---|---|
| Nominal bit rate | 9953280 kbit/s |
| Line code pattern | NRZ |
| Central wavelength (nm) | 1550.12±0.05 |
| -0.5 dB bandwidth (nm) | > 0.4 |
| Compensated dispersion (ps/nm) | N1DCU: 1020 (60 km); 1360 (80 km) N2DCU: 680 (40 km); 1020 (60 km); 1360 (80 km) |
| Insertion loss (dB) | Less than 8.3 dB in the case of the N1DCU and less than 3 dB in the case of the N2DCU |
The mechanical specifications of the DCU are as follows:
The maximum power consumption of the DCU at room temperature (25°C) is 0 W.
