Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | SSN1MR2A |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| Type: | Fiber Identifier | SSN1MR2A: | 2-channel Optical Add/drop Multiplexing Board |
|---|---|---|---|
| Port: | Shenzhen |
The MR2A is applied to the DWDM system. The channel spacing is 0.8 nm. The MR2A supports the add/drop multiplexing function between any two adjacent wavelengths.
Table 1 provides the functions and features of the MR2A.
| Function and Feature | MR2A |
|---|---|
| Basic functions | Adds/Drops any two adjacent standard wavelengths defined in ITU-T G.692 (DWDM). The signals are transparently transmitted and the operating wavelength ranges from 1535.82 nm to 1560.61 nm. |
| OTM function | One MR2A board can work as a two-channel add/drop OTM station, as shown in Figure 1. Two MR2A boards can be cascaded to work as a four-channel add/drop OTM station, as shown in Figure 2. |
| OADM function | Works as a two-channel add/drop OADM station when working with the LWX. For details, see Figure 3. |
| Central wavelength | Supports the standard wavelengths defined in ITU-T Recommendations. The channel spacing is 100 GHz. |
The technical specifications of the MR2A include the parameters specified for optical interfaces, laser safety class, mechanical specifications, and power consumption.
Table 1 lists the parameters specified for the optical interfaces of the MR2A.
| Parameter | Value |
|---|---|
| Operating wavelength range (nm) | The operating wavelength range is from 1535.82 nm to 1560.61 nm. The working wavelengths can be any two adjacent standard wavelengths defined in ITU-T G.692 (DWDM). |
| Line code pattern | NRZ |
| Channel spacing (GHz) | 100 |
| Insertion loss on the add channel or drop channel (dB) | < 2 |
| Adjacent channel isolation (dB) | > 25 |
| Non-adjacent channel isolation (dB) | > 35 |
| -0.5 dB channel bandwidth (nm) | < ±0.11 |
The safety class of the laser on the board is Class 1. The maximum launched optical power of the optical interfaces is less than 10 dBm (10 mW).
The mechanical specifications of the MR2A are as follows:
The maximum power consumption of the MR2A at room temperature (25°C) is 0 W.
