Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | TN11MR2 |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| Type: | Fiber Identifier | TN11MR2: | 2-channel Optical Add/drop Multiplexing Board |
|---|
The MR2 is applied to the dense wavelength division multiplexing (DWDM) system. The channel spacing is 0.8 nm. The MR2 supports the add/drop multiplexing function and channel expansion function.
Table 1 provides the functions and features of the MR2.
| Function and Feature | MR2 |
|---|---|
| Basic functions | Adds/Drops and multiplexes any two signals to/from the multiplexed signals. |
| Channel expansion | Provides the interface to cascade another optical add/drop multiplexing board to realize the expansion of the add/drop channel. |
The feature code of the MR2 contains eight characters, which indicate the frequencies of the two channels of optical signals processed by the MR2.
Table 1 describes the feature code of the MR2.
| Feature Code | Indication | Description |
|---|---|---|
| First four (1–4) characters | Frequency of optical signals | The four characters are the last four characters of the figure that indicates the frequency of the first channel of optical signals processed by the MR2. |
| Last four (5–8) characters | Frequency of optical signals | The four characters are the last four characters of the figure that indicates the frequency of the second channel of optical signals processed by the MR2. |
Consider the TN11MR2 whose feature code is "93609370" as an example. The meaning of the feature code of the TN11MR2 is as follows:
The technical specifications of the MR2 include the parameters specified for optical interfaces, laser safety class, mechanical specifications, and power consumption.
Table 1 lists the parameters specified for the optical interfaces of the MR2.
| Optical Interface | Parameter | Value |
|---|---|---|
| - | Operating wavelength range (nm) | 1529 to 1561 |
| - | Channel spacing (GHz) | 100 |
| IN-D1 IN-D2 | 0.5 dB passband bandwidth (nm) | ≥ ±0.11 |
| Insertion loss (dB) on the drop channel | ≤ 1.5 | |
| Adjacent channel isolation (dB) | > 25 | |
| Non-adjacent channel isolation (dB) | > 35 | |
| A1-OUT A2-OUT | 0.5 dB passband bandwidth (nm) | ≥ ±0.11 |
| Insertion loss (dB) on the add channel | ≤ 1.5 | |
| IN-MO MI-OUT | Insertion loss (dB) | ≤ 1.0 |
| Isolation (dB) | > 13 |
The safety class of the laser on the board is Class 1M. The maximum launched optical power of the optical interfaces is within the range from 10 dBm (10 mW) to 22.15 dBm (164 mW).
The mechanical specifications of the MR2 are as follows:
The power consumption of the MR2 at room temperature (25°C) is 0 W.
