Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | SSN1CMD2 |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| Type: | Fiber Identifier | SSN1CMD2: | 2-channel Bidirectional CWDM Optical Add/drop Multiplexing Board |
|---|
The CMD2 is used to add/drop two channels of signals in a CWDM system.
Table 1 provides the functions and features of the CMD2.
| Function and Feature | CMD2 |
|---|---|
| Basic functions | Adds/Drops two channels of signals to/from the multiplexed channel in two directions. |
| CWDM specifications | Complies with CWDM technical specifications. |
The technical specifications of the CMD2 include the parameters specified for optical interfaces, laser safety class, mechanical specifications, and power consumption.
Table 1 lists the parameters specified for the optical interfaces of the CMD2.
| Optical Interface | Parameter | Value |
|---|---|---|
| - | Operating wavelength range (nm) | 1471 to 1611 |
| - | Channel spacing (nm) | 20 |
| IN1-D11 IN1-D12 IN2-D21 IN2-D22 | 1.0 dB passband bandwidth (nm) | ≥ 13.0 |
| Insertion loss (dB) on the drop channel | < 1.5 | |
| Adjacent channel isolation (dB) | > 30 | |
| Non-adjacent channel isolation (dB) | > 40 | |
| A11-OUT1 A12-OUT1 A21-OUT2 A22-OUT2 | 1.0 dB passband bandwidth (nm) | ≥ 13.0 |
| Insertion loss (dB) on the add channel | < 1.5 | |
| - | Reflectance (dB) | < -40 |
The safety class of the laser on the board is Class 1M. The maximum launched optical power of the optical interfaces is within the range from 10 dBm (10 mW) to 22.15 dBm (164 mW).
The mechanical specifications of the CMD2 are as follows:
The power consumption of the CMD2 at room temperature (25°C) is 0 W.
