Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | SSN1FXO12 |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| Type: | Fiber Identifier | SSN1FXO12: | 12-port FXO Processing Board |
|---|
An FXO12 board transmits or receives 12-channel analog voice signals, and provides alarms and events for maintenance.
Table 1 provides the functions and features supported by an FXO12 board.
| Function and Feature | Description |
|---|---|
| Basic functions | Provides 12 FXO ports.
|
| Port |
|
| Service processing | Transmits/Receives and processes 12-channel 64 kbit/s signals. |
| Overhead processing | Supports the setting and query of the V5 and J2 bytes. |
| Alarms and events | Provides alarms and events for maintenance and fault locating. |
| Maintenance features |
|
The technical specifications of the FXO12 include the interface specifications, mechanical specifications, and power consumption.
Table 1 lists the parameters specified for the electrical interfaces of the FXO12.
| Parameter | Value |
|---|---|
| Type of interface | RJ-11 |
| Channel bandwidth (Hz) | 300 to 3400 |
| Port Impedance (Ω) |
Default value: 600-ohm interface |
| TX Gain (dB) | -16.5 to 13.5, in steps of 0.5 Default value: 0.0 |
| RX Gain (dB) | -16.5 to 11.0, in steps of 0.5 Default value: -3.5 |
| Specifications of the interface | Complies with ITU-T G.711, G.712, Q.552. |
The mechanical specifications of the FXO12 are as follows:
The maximum power consumption of the FXO12 at room temperature (25°C) is 24 W.
