Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | SSN4SLD6401 |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| Type: | Fiber Identifier | SSN4SLD6401: | 2xSTM-64 Optical Interface Board, I-64.1 |
|---|
The SLD64 receives and transmits 2xSTM-64 optical signals, processes overhead bytes, and performs the MSP protection.
Table 1 describes the functions and features of the SLD64.
| Function and Feature | Description |
|---|---|
| Basic functions | Provides two optical interfaces to transmit and receive 2xSTM-64 optical signals. Processes 2xSTM-64 standard services or concatenated services, which are encapsulated in XFP format. |
| Specifications of the optical interface | Supports different types of standard optical interfaces, namely, the I-64.1 and S-64.2b. The characteristics of the optical interfaces comply with ITU-T G.691. The N4SLD64 provides standard P1L1-2D2 optical ports, whose specifications comply with ITU-T G.959. The N4SLD64 supports the CWDM and DWDM colored optical interfaces. The optical interface uses the LC connector. The CWDM optical interface supports the transmission distance of 70 km, and the DWDM optical interface supports the transmission distances of 80 km. N4SLD64 supports one-fiber bidirectional optical modules. |
| Specifications of the optical module |
|
| Service processing | Supports the VC-12 services, VC-3 services, VC-4 services, VC-4-4c concatenation services, VC-4-8c concatenation services, VC-4-16c concatenation services, and VC-4-64c concatenation services. |
| Overhead processing |
|
| Alarms and performance events | Reports various alarms and performance events. |
| Specifications of the REG | Does not support the REG. |
| Protection schemes |
|
| Maintenance features |
|
The number code that follows the board name in the bar code is the feature code of the board. The feature code of the SLD64 indicates the type of optical interface.
Table 1 describes the relationship between the feature code of the SLD64 and the type of optical interface.
| Board | Feature Code | Type of Optical Interface |
|---|---|---|
| SSN1SLD6401, SSN4SLD6401 | 01 | I-64.1 |
| SSN1SLD6402, SSN4SLD6402 | 02 | S-64.2b |
| SSN4SLD6403 | 03 | P1L1-2D2 |
The technical specifications of the SLD64 include the parameters specified for optical interfaces, laser safety class, mechanical specifications, and power consumption.
Table 1 lists the parameters specified for the optical interfaces of the SLD64.
| Port type | Description |
|---|---|
| I-64.1 | 2 km STM-64 two-fiber bidirectional optical interfaces |
| S-64.2b | 40 km STM-64 two-fiber bidirectional optical interfaces |
| P1L1-2D2 | 80 km STM-64 two-fiber bidirectional optical interfaces |
Table 2 list the parameters specified for the colored optical interfaces of the N4SLD64.
| Port type | Description |
|---|---|
| 70 km CWDM | 70 km CWDM STM-64 optical interfaces |
| 80 km DWDM | 80 km DWDM STM-64 optical interfaces |
The safety class of the laser on the board is Class 1. The maximum launched optical power of the optical interfaces is less than 10 dBm (10 mW).
The mechanical specifications of the SLD64 are as follows:
The maximum power consumption of the N1SLD64 at room temperature (25°C) is 41 W.
The maximum power consumption of the N4SLD64 at room temperature (25°C) is 20 W.
