| Type: | Fiber Identifier | SSN1SLH1: | 16xSTM-1 Optical Interface Board |
|---|
The SLH1 processes STM-1 optical and electrical signals.
Table 1 provides the functions and features of the SLH1.
| Function and Feature | SLH1 |
|---|---|
| Basic functions | Processes 16xSTM-1 signals. |
| Specifications of the optical module |
|
| Service processing | Supports the VC-12 services, VC-3 services, and VC-4 services. |
| Overhead processing |
|
| Alarms and performance events | Reports various alarms and performance events, which facilitates the management and maintenance of the equipment. |
| Protection schemes |
|
| Maintenance features |
|
When the SLH1 works with different interface boards and electrical interface switching boards, the access capabilities for the STM-1 signals are different. For details, refer to Table 2.
| Interface Board | SLH1 |
|---|---|
| None | The SLH1 cannot transmit/receive signals. |
| EU08 | Transmits/Receives and processes 8-channel or 16-channel electrical signals. |
| OU08 | Transmits/Receives and processes 8-channel or 16-channel optical signals. |
| EU08 + OU08 | Transmits/Receives and processes 8-channel electrical signals and 8-channel optical signals. |
| EU08 + TSB8 | Transmits/Receives and processes 8-channel or 16-channel STM-1 electrical signals, and realizes the 1:N (N≤3) TPS protection. |
The technical specifications of the SLH1 include the parameters specified for optical interfaces, mechanical specifications, and power consumption.
The OU8 or EU08 provides interfaces for the SLH1. For the parameters specified for the interfaces, see Technical Specifications of the EU08 and Technical Specifications of the OU08.
The mechanical specifications of the SLH1 are as follows:
The maximum power consumption of the SLH1 at room temperature (25°C) is 27 W.
