Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | SSN1CQ1 |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| Type: | Fiber Identifier | SSN1CQ1: | 4-channel Channelized STM-1 CES Optical Interface Board |
|---|
The CQ1 receives four-port channelized STM-1 services, and works with the PEG8 to process CES service signals.
Table 1 provides the functions and features of the CQ1.
| Function and Feature | CQ1 | |
|---|---|---|
| Basic functions | Transmits and receives four-port channelized STM-1 optical signals, and works with the PEG8 to process four-port channelized STM-1 CES services. | |
| Interface types | Supports different types of standard optical interfaces, namely, S-1.1, L-1.1, and L-1.2 to meet requirements for transmission distances. The characteristics of the optical interfaces comply with ITU-T G.957. | |
| Interface characteristics | ALS | Not supported |
| Loopback types of the port | Inloops and outloops at STM-1 ports Inloops and outloops on VC-12 paths | |
| Auto disabling of port loopback | Supported | |
| Detection and query of optical module information | Supported | |
| Hot insertion and removal of SFP optical modules | Supported | |
| CES | Supported CES services | 252 |
| Supported emulation mode | CESoPSN SAToP NOTE: For CES services in CESoPSN mode, CQ1 boards can compress idle timeslots to improve the bandwidth utilization on the NNI side. | |
| Jitter buffering time | 0.375 ms to 16 ms; increment: 0.125 ms | |
| Packet loading time | 0.25 ms TO 5 ms; increment: 0.125 ms NOTE:
| |
| Protection scheme | Supports the 1+1 and 1:1 Packet-based linear MSP. | |
| SSM protocol | Supported | |
| PRBS | Not supported | |
| Query of laser transmission distance | Supported | |
The technical specifications of the CQ1 include the specifications of optical interfaces, laser safety class, mechanical specifications, and power consumption.
Table 1 provides the specifications of the optical interfaces on the CQ1.
| Port type | Description |
|---|---|
| S-1.1 | 15 km STM-1 two-fiber bidirectional optical interfaces |
| L-1.1 | 40 km STM-1 two-fiber bidirectional optical interfaces |
| L-1.2 | 80 km STM-1 two-fiber bidirectional optical interfaces |
The safety class of the laser on the board is Class 1. The maximum launched optical power of the optical interfaces is less than 10 dBm (10 mW).
The mechanical specifications of the N1CQ1 are as follows:
The maximum power consumption of the N1CQ1 at the room temperature (25°C) is 10 W.
