Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | SSN1SEP1 |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| Type: | Fiber Identifier | SSN1SEP1: | 8xSTM-1 Line Processing Board |
|---|
The SEP1 processes STM-1 signals. When the interfaces are available on the front panel of the SEP1 (the logical board of the SEP1 is displayed as SEP1 on the U2000), the SEP1 processes 2xSTM-1 electrical signals. When the SEP1 is used with the interface board (the logical board of the SEP1 is displayed as SEP on the U2000), the SEP1 processes 8xSTM-1 optical/electrical signals or 4xSTM-1 electrical signals. The physical boards of the two types of logical boards (SEP1 and SEP) are the SEP1. When the logical boards do not need to be differentiated, both the SEP1 and SEP are defined as SEP1.
Table 1 provides the functions and features of the SEP1.
| Function and Feature | SEP1 |
|---|---|
| Basic functions |
|
| Service processing | Supports the VC-12 services, VC-3 services, and VC-4 services. |
| Overhead processing |
|
| Alarms and performance events | Reports various alarms and performance events, which facilitates the management and maintenance of the equipment. |
| Protection schemes |
|
| Maintenance features |
|
When the SEP1 works with different interface boards and electrical interface switching boards, the access capabilities for the STM-1 signals are different. For details, refer to Table 2.
| Interface Board | SEP1 |
|---|---|
| None | Transmits/Receives and processes 2xSTM-1 electrical signals, but does not support the TPS protection. |
| EU04 | Transmits/Receives and processes 4xSTM-1 electrical signals. |
| EU08 | Transmits/Receives and processes 8xSTM-1 electrical signals. |
| OU08 | Transmits/Receives and processes 8xSTM-1 optical signals. |
| EU04 + TSB4 | Transmits/Receives and processes 4xSTM-1 electrical signals, and supports the TPS protection. |
| EU08 + TSB8 | Transmits/Receives and processes 8xSTM-1 electrical signals, and supports the TPS protection. |
| EU04 + TSB8 | Transmits/Receives and processes 4xSTM-1 electrical signals, and supports the TPS protection. |
Table 1 lists the parameters specified for the interfaces of the SEP1, When the interfaces are available on the front panel of the SEP1.
| Port type | Description |
|---|---|
| STM-1 electrical interfaces | STM-1 electrical interfaces(SMB) |
The SEP1 can be used with the interface board EU08, or OU08. For the parameters specified for the electrical interfaces, see Technical Specifications of the EU08 and Technical Specifications of the OU08.
The mechanical specifications of the SEP1 are as follows:
The maximum power consumption of the SEP1 at room temperature (25°C) is 16 W.
