OptiX OSN 1500 SSR1SL110 1xSTM-1 optical interface board -- OSN1500

Name: OptiX OSN 1500 SSR1SL110 1xSTM-1 optical interface board -- OSN1500
Brand: Huawei
SKU: SSR1SL110
Availability: InStock
ISBN: 14208824

Product Details:

Place of Origin:	China
Brand Name:	Huawei
Certification:	CE FCC RoHS
Model Number:	SSR1SL110

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiable
Price:	Negotiable
Packaging Details:	Export carton package
Delivery Time:	7-15 days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	200 Piece/Pieces per Week

Contact Now

Detailed Product Description

Type:	Fiber Identifier	SSR1SL110:	1xSTM-1 Optical Interface Board, S-1.1

The SL1 transmits and receives STM-1 optical signals, performs O/E conversion for the STM-1 optical signals, extracts and inserts overhead bytes, and generates alarm signals on the line.

Table 1 provides the functions and features of the SL1.

Table 1 Functions and features of the SL1

Function and Feature	SL1
Basic functions	Transmits and receives 1xSTM-1 optical signals.
Specifications of the optical interface	Supports different types of standard optical interfaces, namely, the I-1, S-1.1, L-1.1, L-1.2, and Ve-1.2. The characteristics of the optical interfaces of the I-1, S-1.1, L-1.1, and L-1.2 types comply with ITU-T G.957. The characteristics of the optical interface of the Ve-1.2 type comply with the standards defined by .
Specifications of the optical module	Supports the detection and query of the information about the optical module. Supports the usage and detection of the small form-factor pluggable (SFP) optical module, which facilitates the maintenance of the optical module. Provides the automatic laser shutdown (ALS) function. The optical interface supports the setting of the on/off state of a laser.
Service processing	Supports the VC-12 services, VC-3 services, and VC-4 services. The N2SL1 supports the AU-3 services.
Overhead processing	Processes the section overheads of the STM-1 signals. Supports the transparent transmission and termination of the path overheads. Supports the setting and query of the J0, J1, and C2 bytes. Supports one channel of ECC communication.
Alarms and performance events	Provides various alarms and performance events, which facilitates the management and maintenance of the equipment.
Protection schemes	Supports the Two-fiber ring MSP, only supports two-fiber unidirectional MSP ring. Supports the Four-fiber ring MSP. Supports the Linear MSP. Supports the SNCP. Supports the SNCMP. Supports the SNCTP.
Maintenance features	Supports inloops and outloops at optical interfaces. The N1SL1/R1SL1 supports inloops on VC-4 paths. Supports warm resets and cold resets. The warm reset does not affect services. Supports the query of the manufacturing information of the board. Supports the in-service loading of the FPGA. Supports the upgrade of the board software without affecting services. The N2SL1 supports the TCM function. Supports the press-to-collect function in fault data collection.

The number code that follows the board name in the bar code is the feature code of the board. The feature code of the SL1 indicates the type of optical interface.

Table 1 provides the relationship between the feature code of the SL1 and the type of optical interface.

Table 1 Relationship between the feature code of the SL1 and the type of optical interface

Board	Feature Code	Type of Optical Interface
SSR1SL110, SSN1SL110 and SSN2SL110	10	S-1.1
SSR1SL111, SSN1SL111 and SSN2SL111	11	L-1.1
SSR1SL112, SSN1SL112 and SSN2SL112	12	L-1.2
SSR1SL113, SSN1SL113 and SSN2SL113	13	Ve-1.2
SSR1SL114, SSN1SL114 and SSN2SL114	14	I-1
