Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | ZXD3000 |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| Output Power: | >500W | Output Type: | Single |
|---|---|---|---|
| Output Voltage: | 53.5 | Output Frequency: | 45-65 |
| Output Current: | 62.5 | Input Voltage: | 220V |
| Port: | Shenzhen |
Product Overview
With the multi-mode era coming, ZTE, who is dedicated to providing comprehensivenetwork solutions and delivering the future-oriented quality network for the operators,developed the ground breaking SDR unified platform with the essential feature to supportmulti-mode and multi-band radio access.Based on this innovative SDR platform, ZTE promotes a series of base stations to satisfydifferent scenario requirements, including Indoor Macro, Outdoor Macro, Distributed,Outdoor Micro, and Mini BTS.These SDR-based serial base stations aim to design a unified network which can bringseamless experience to operators. In GSM, UMTS or mixed mode, it enables operatorsto save CAPEX and OPEX significantly because they only need to deploy a Uni-RadioAccess Network, compared to the independent GSM and UMTS networks.ZXSDR BS8900A is one outdoor macro BTS, providing an all in one solution for powersupply, battery, and transmission integration. It offers GSM/UMTS dual-mode networkingcapability and provides a future-proof solution for smooth evolution to Enhanced EDGE,HSPA+ and LTE. BS8900A appearance is shown in Figure 1-1. In the followingchapters, a general description will be given to ZXSDR BS8900A (hereafter referred as BS8900A)
Product Architecture
BS8900A adopts standard 19 inches rack structure. It is composed of outdoor baseband cabinet BC8910A, outdoor radio cabinet RC8910A, outdoor radio cabinet RC8911A, and battery cabinet PC8910A. Typical configuration dimension of BS8900A is 1600mm *600mm * 600mm (H*W*D). With the 200mm bottom base and 16mm top cover, the totalheight reaches 1816mm.Outdoor baseband cabinet is also called site support cabinet, including power distributionshelf, fan shelf, baseband unit shelf, ventilation shelf, and additional space reserved for transmission or other equipments. Outdoor RF cabinets are used for containing radio unit,maximum supporting 6 RSUs. Battery cabinet supports maximum 2×150AH battery.BS8900A complete style is shown in the following figure, consisting of one BC8910A,one RC8910A and one PC8910A. BS8900A single rack supports up to 60 GSM TRXs or30 UMTS CSs.BS8900A Physical Architecture (Complete Style)
There are mainly five parts in BC8910A: baseband unit, power supply system, powerdistribution module, heat exchanging system and reserved space for transmission orother equipments. Together with the fan and ventilation vessel, the heat exchangerlocated in the cabinet door makes the heat exchanging system. BC8910A hardwarearchitecture is shown in the following figure
Figure 2-3 Site Support Cabinet BC8910A (AC Power Supply)In the case of DC power supply, AC/DC power system (5U) should be replaced by DCpower distribution with 2U in height.Figure 2-4 Site Support Cabinet BC8910A (DC Power Supply)
The power system of BC8910A contains 4×30A AC/DC rectifiers. It is 5U in height. Itsconfiguration depends on the load and the backup battery capacity.
RC8910A consists of 6 RF modules and fan control system. Its physical appearance isshown in the following figure.Figure 2-16 Outdoor Radio Cabinet RC8910A
RC8911A accommodates 3 RF modules, 4 batteries and fan control subsystem. Itsphysical appearance is shown in the following figure. RC8911A can be divided into leftand right part. In the right part 3 RSUs can be installed, and in the left part 4 batteries canbe arranged. The capacity of the 4 batteries is 150AH. For details of RF Modules pleaserefer to chapter 2.2.2.
PC8910A is an outdoor battery cabinet, and it works with BC8910A and RC8910A. Thefollowing figure shows the structure of PC8910A and it contains 8 batteries, with thecapacity of 2×150AH
Table 3-1 BS8900A Physical Indices
Table 3-2 Different Combination of BS8900A
R8840 is a UMTS multi-carrier radio unit, working on 2100MHz/AWS. R8840 supports maximum 4 carriers, the output power is 60W. R8840 module consists of MCPA (multi-carrier power module) module, transceiver module, duplex filter LNA and RPWAC/DC (Power for AC or DC). There are one TX/RX port and one RX port for connecting antenna. R8840 employs compact cabinet design, as shown in Figure 16. Dimension of R8840 is 370×320×160mm (H×W×D).
R8860 is multi-carrier RF module, working on 850/900/1800/1900MHz. R8860 can be configured as GSM only, UMTS only or mixed mode module. R8860 can be configured to 1 to 6 TRX in GSM mode. In case of GMSK modulation, 80W TOC output power can be provided. If R8860 is used as UMTS mode, it can support 4 carriers with 80W TOC output power. In mixed mode, R8860 can support 4 GSM TRX and 1 UMTS carriers or 2 GSM TRX and 2 UMTS carriers.
R8880 is a multi-carrier RF module. R8880 can be configured as UMTS mode. It can process 2 received signals and 2 transmitted signals. Each one can support 2*2 MIMO in HSPA+ mode on 2100MHz. Its output power achieves up to 2*60W (TOC). It is mainly used for outdoor macro coverage and also used for indoor coverage signal source. R8880 can be configured as UMTS mode. R8880 can support 3 carriers when it ensures the 2*20W output power for each carrier.
R8882 is a multi-carrier RF module. R8880 can be configured as UMTS mode. It can process 4 received signals and 2 transmitted signals. Each one can support 2*2 MIMO in HSPA+ mode on 2100MHz. Its output power achieves up to 2*60W (TOC). It is mainly used for outdoor macro coverage and also used for indoor coverage signal source. R8880 can support 3 carriers when it ensures the 2*20W output power for each carrier.
Return Material Authorization (RMA) Process
Standard Hardware Warranty Policy:
Original new sealed ZTE product: 1 Year
The Support Contacts:
If your ZTE products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.
Cargo will be delivered within 1 day after payment arrived. Tracking Number will be offered once delivery done.
Uonel is one of the biggest Network Hardware distributor in china, founded in 2008. We are a global provider of netwotking products with more than 5000 customers.
We provide original new Huawei & ZTE & Cisco & Fiberhome & H3C & Ericsson & Alcatel Lucent & Emerson with Routers,Switches,Firewalls,Wireless APs & controllers,OLTs,GPON modems,optical transceivers.we can provide Plenty of Stock, Fast Delivery, Better price, and original guarantee.
Most of our technical engineers has considerable experience in company,we can provide network design&planning,configration,troubleshooting,maintenance and training service in world wide.
Contact Person: Mr. Leo yang
Tel: +86 15684227158
