Base station antenna HUAWEI COMBA MOBI TONGYU etc or customized 2/4/6/8 ports for GSM/UMTS/CDMA/LTE

Negotiable
MOQ
Negotiable
Price
Base station antenna HUAWEI COMBA MOBI TONGYU etc or customized 2/4/6/8 ports for GSM/UMTS/CDMA/LTE
Features Gallery Product Description Request A Quote
Features
Specifications
Application: Base Station Antenna
Function: Antenna With RET
Frequency Band: Single Band/ Dual Band/Tri-band
Work Mode: CDMA GSM UMTS LTE
Port: Hongkong Or Shenzhen
Basic Infomation
Place of Origin: China
Brand Name: Huawei
Certification: CE FCC RoHS
Model Number: Base station antenna
Payment & Shipping Terms
Packaging Details: Export carton package
Delivery Time: 7-15 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 200 Piece/Pieces per Week
Product Description
Base station antenna HUAWEI COMBA MOBI TONGYU etc or customized 2/4/6/8 ports for GSM/UMTS/CDMA/LTE 0Base station antenna HUAWEI COMBA MOBI TONGYU etc or customized 2/4/6/8 ports for GSM/UMTS/CDMA/LTE 2Base station antenna HUAWEI COMBA MOBI TONGYU etc or customized 2/4/6/8 ports for GSM/UMTS/CDMA/LTE 4
Frequency range (MHz)790-9601710–2170
Polarization +45°, –45°
Average gain (dBi)15~18 dBi17~19 dBi
impedance50 Ω
VSWR  <1.5
Isolation, between ports ≥ 28 dB
Intermodulation IM3 (2 x 43 dBm carrier)
Max. input power/port  (at 50 °C ambient Temp)500 W 300 W
Horizontal Pattern:
Half-power beam width -3 dB (°)65±665±6
Front-to-back ratio (180°±30°) > 25
Vertical Pattern:
Half-power beam width -3 dB (°)9.56
Adjustable Electrical Tilt Range0 ~ 10°T 0~ 10°T
 Adjustable Mechanical Tilt Range0 ~ 14°0 ~ 14°
Side lobe suppression (1st lobe above main beam)> 16 dB> 16 dB
Support RET
For more detail, please contact me as following information:
Base station antenna HUAWEI COMBA MOBI TONGYU etc or customized 2/4/6/8 ports for GSM/UMTS/CDMA/LTE 6



Our Services



100% Low Price Guarantee:
 Uonel provides high-quality products at low wholesale prices
100% Quality Assurance:
All items are ORIGINAL NEW  and GENUINE only.
Additional Free Technical Support:

Our Huawei Expert Consultancy support over the phone, by chat, by email or by login remotely.

100% Money Back Guarantee:
You can contact our customer service team to exchange or return any product that you bought from us.

Flexible Secure Payment & Shipment:
Verified authorization: Mcafee Secure, VeriSign Secured



Packaging & Shipping



MOQ: 1 pcs

Port: Hongkong / Shenzhen

Lead time: Within 3-10 working days after receipt payment.

Shipment: Express, Air, Sea

Sample availability: Yes( not free)

Package information: carton package with Huawei / ZTE/ Emerson original package or as discussion



Base station antenna HUAWEI COMBA MOBI TONGYU etc or customized 2/4/6/8 ports for GSM/UMTS/CDMA/LTE 8
