Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | IAD132E |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| Product Name: | IAD132E | Maximum Number: | 100 (a Maximum Of 96 FXS Ports |
|---|---|---|---|
| Port:: | 24 FXO Ports Or 1 E1/T1 Port | Codec:: | G.711A/μ, G.729a/b, And ILBC |
| DC Power Supply:: | --48V To --60 V | Dimensions:: | 86.1 Mm * 442 Mm * 310 Mm |
| Type:: | VoIP Gateway | Terminal Type:: | Analog Phones, IP Phones, Video |
| Trunk Protocol:: | SS7, R2, PRI, QSIG, SIP | AC Power Supply:: | 100 V To 240 V, 50 Hz/60 Hz |
| Port: | HONGKONG Port & Shenzhen Port |
Huawei media access gateway eSpace IAD132E(T) IAD132E(T)-32S
Huawei's unified communication gateways offer rich IP-PBX telephony and conferencing capabilities for up to 20,000 users and support for analog equipment in hybrid environments.
U1900 Series Gateways provide upstream connections to the Public Switched Telephone Networks (PSTNs) or to voice switches in private networks. Downstream support for IP phones, analog phones, and soft terminals brings effective communication and collaboration to every user.
Intelligent routing, whitelist/blacklist features, instant messaging, and carrier-grade reliability deliver high-quality IP-based voice and communications services for enterprises at low TCO.
| Item | Specifications | |
|---|---|---|
| Maximum number of users | 100 (a maximum of 96 FXS ports for analog users or 100 SIP users) | |
| Terminal type | Analog phones, IP phones, video phones and soft clients | |
| Port | 24 FXO ports or 1 E1/T1 port | |
| Trunk protocol | SS7, R2, PRI, QSIG, SIP | |
| Codec | G.711A/μ, G.729a/b, and iLBC | |
| Number of meeting participants | A maximum of 12 meeting participants which can be allocated to 4 meeting halls (each hall can support up to 12 participants by maximum) | |
| Power supply | AC: 100 V to 240 V, 50 Hz/60 Hz DC: –38.4 V to –60 V (typical value: –48 V) Redundancy: 1+1 backup | |
| Maximum power consumption | 200 W (full configuration) | |
| Dimensions (H * W * D) | Standard 19-inch 2 U subrack 86.1 mm * 442 mm * 310 mm | |
| Weight | 8 kg (full configuration) | |
| Environment | Temperature | Storage temperature: –40° C to +70° C Long-term operating temperature: 0° C to 45° C Short-term operating temperature: –5° C to +55° C |
| Relative humidity | 5% to 95% (without condensation) | |
| Dustproof | Less than 180 mg/m³ dust in the air (Dustproof measures should be taken in the work environment) | |
| System Reliability | 99.995% | |
| Maintainability | Remote maintenance, automatic configuration, log collection, and Daylight Saving Time (DST) | |
| Manageability | Centralized/remote equipment management, signaling tracing, resource management, alarm management, and quick deployment | |
U1981 core voice gateways provide call control services network-wide. The branches can use different model eSpace U1900 series gateways as local voice gateways. These local voice gateways support local regeneration to ensure service continuity.
Using narrow and broadband trunks, local voice gateways can connect to external networks, such as PSTN, to implement communication between internal and external (mobile and fixed-line) users. In those cases, SIP phones can connect directly. Analog phones and fax machines can connect through Integrated Access Devices (IADs).
Based on IPT application scenarios, UC application servers deploy at the same time to enrich communication channels and improve communication efficiency with a wide range of UC services. Services include presence, Instant Messaging (IM), and multimedia conferencing. In this case, the U1981 works as a core voice gateway.
