Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| Model: | SLDMSITE05 | Part Number: | 02310UNM |
|---|
We can offer more accessories of RTN 905:
SLDMSITE02 RTN 905 4 * GE (RJ45) + 2 * GE (SFP) + 16 * E1 + 2 * TDM cascade interface +2 way IF unit IDU module (-48VDC) with IDU installation accessories
SLDMSITE03 RTN 905 4 * GE (RJ45) + 2 * GE (SFP) + 16 * E1 + 2 * STM-1 (SFP) + 2 * TDM cascade interface +1 channel unit IDU module (-48VDC) Contains IDU installation accessories
TNPMHOST0200 PTN 905A system, 2 GE / FE (Combo) and 4 E1 (120 ohm)
TNPMHOST0300 PTN 905B system, 2 GE / FE (Combo), 2 GE / FE (light) and 2 GE / FE (electrical)
SLDMSITE01 RTN 905 basic configuration unit 4 * GE (RJ45) + 2 * GE (SFP) + 16 * E1 + 2 * TDM cascade interface +1 way IF unit IDU module (-48VDC) with IDU installation accessories
SLDMSITE04 RTN 905 4 * GE (RJ45) + 2 * GE (1000BaseLX, 1310-LC) + 16 * E1 + 2 * TDM cascade interface +2 way IF unit IDU module (-48VDC) with IDU installation accessories
SLD3YU201 RTN 905 System 2 * GE (RJ45) + 2 * GE (RJ45 / Ethernet power supply function) + 2 * GE (SFP) + 16 * E1 + 2 * STM-1 (SFP) +2 multi-function port +2 Channel IF unit IDU module (-48VDC)
SLD3IRU101 RTN 905 system 4 * GE (RJ45) + 2 * GE (SFP) + 16 * E1 +SLM-1 (SFP) + 2-way multi-function port 1-way IF unit IDU module (-48VDC)
SLDMSITE06 RTN 905 4 * GE (RJ45) + 2 * GE (SFP) + 16 * E1 + 2 * STM-1 (SFP) +2 Multifunctional 1-way IF Unit IDU Module (-48VDC) 1E with IDU installation accessories
SLDMSITE07 RTN 905 2 * GE (RJ45) + 2 * GE (RJ45 / Ethernet power supply function) + 2 * GE (SFP) + 16 * E1 + 2 * STM-1 (SFP) +2 way IF unit IDU module (-48VDC) -2E with IDU installation accessories
Huawei's RTN 900 series is the industry's first TDM/Hybrid/Packet/Routing integrated IP microwave product. It can meet voice transmission requirements in the 2G era, voice and data transmission requirements in the 3G era, as well as broadband data transmission requirements in the LTE era, effectively protecting operator investments in infrastructure.
HUAWEI RTN905
HUAWEI RTN910
HUAWEI RTN950A
HUAWEI RTN980
RTN905 | RTN910 | RTN950A | RTN980 | ||||
Support frequency | 6/7/8/10/10.5/11/13/15/18/23/26/28/32/38/42 GHz | ||||||
Channel spacing | 3.5/7/14/28/40/50/56MHz | ||||||
Maximum RF direction | 1U/2 | 2U/6 | 2U/6 | 5U/14 | |||
Maximum throughput | > 600Mbps | ||||||
Packet switching capability | 8Gbps | 10Gbps | 10Gbps | 22Gbps | |||
Interface Type | E1/STM-1/FE/GE | E1/STM-1/FE/GE | E1/STM-1/FE/GE | E1/STM-1/STM-4 /FE/GE | |||
IEEE1588v2 | SUPPORT | ||||||
Working environment | Working temperature: IDU -5℃~+60℃ ; ODU -35℃~+55℃ Relative humidity: IDU 5%~95% ,ODU 5%~100% | ||||||
Power supply range | DC Power -38.4V ~ -57.6V AC Power 220V | ||||||
IDU Weight | 2.7kg | 5.4kg | 5.4kg | 15.4kg | |||
HUAWEI RTN310
HUAWEI RTN360
HUAWEI RTN380
Shenzhen Hong Telecom Equipment Limited, formal distributor of Huawei, ZTE, Cisco, Fiberhome, H3C,Ericsson, Alcatel Lucent and Emerson, we provide complete series of Huawei,ZTE and Emerson.
Comparing with Huawei & ZTE & Cisco & Fiberhome & H3C & Ericsson & Alcatel Lucent & Emerson, we can provide Plenty of Stock, Fast Delivery, Better price, and original guarantee.
1. 5-10 Working days after received the payment.
2. Shipment: Sea transportation & Air transportation ( DHL / UPS / TNT / Fedex / EMS )
1. Original Carton Package.
2. As customers' requirement.
