WDM OSN902 M201 OTU Board TNJ1M201

Negotiable
MOQ
Negotiable
Price
WDM OSN902 M201 OTU Board TNJ1M201
Features Gallery Product Description Request A Quote
Features
Specifications
Model: TNJ1M201
OSN 902 Dimensions (H X W X D): 86.1 Mm X 442 Mm X 600 Mm
Maximum Capacity: 2.4 Tbit/s
Number Of Service Slots: 6
Cabinet: 19-inch Cabinet
Transport/Storage Temperature: -40°C (-104°F) To +70°C (158°F)
Humidity: 5% To 95%, Non-condensing
Altitude: < 5000 M
Rate Per Channel (maximum): 100G/200G
Basic Infomation
Place of Origin: China
Brand Name: Huawei
Certification: CE FCC RoHS
Model Number: OSN902
Payment & Shipping Terms
Packaging Details: Export carton package
Delivery Time: 7-15 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 200 Piece/Pieces per Week
Product Description
Product Introduction



WDM OSN902 M201 OTU Board TNJ1M201





Huawei OSN902 DCI Platform


The OSN902 is a WDM transmission platform customized for Data Center Interconnect (DCI) applications. Its large transmission capacity, adaptation to installation conditions in DC equipment rooms, and simple management mode provide an optimal user experience on DCI carrier networks.

Based on open TSDN software architecture, the OSN902 provides various open interfaces. DCI users can perform secondary development to integrate this product's management into DC device management systems, reduce the difficulties in routine maintenance, and ensure the development of rapidly increasing DC services.




Product Specification

The Huawei OptiX OSN902 Specifications:

OptiX OSN902 Specifications
Details
Dimensions (H x W x D)
86.1 mm x 442 mm x 600 mm, 19 inch cabinet
Number of Service Slots
6 slots, 2.4T/Subrack
Line Side
Single Wavelength 100G (PDM-QPSK)/200G (PDM-16QAM) programmable
Client Side
Pluggable QSFP+/QSFP28, supporting 10 GE/40 GE/100 GE service access
Channel Spacing
100 GHz fixed grid for 40/48 wavelengths
50 GHz fixed grid for 80/96 wavelengths
37.5 GHz to 400 GHz flex grid
Rate per Channel (maximum)
100G/200G
Management
CLI/SNMP/NETCONF/U2000/Corba
Operational Features
L1 Encryption (AES256)
LLDP
Power Supply
1+1 power supply redundancy
AC power: 90V to 264V AC
High voltage DC power: 192V to 288V HVDC
Heat Dissipation
2+1 fan module redundancy, ventilation from front to rear
