ZTE ZXMP M600 CWU ZTE DWDM transmission ZXMP M600

Product Details:

Place of Origin:	China
Brand Name:	ZTE
Certification:	CE FCC RoHS
Model Number:	ZXMP M600

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiable
Price:	Negotiable
Packaging Details:	Export carton package
Delivery Time:	7-15 days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	200 Piece/Pieces per Week

Contact Now

Detailed Product Description

Transmission Capacity:	45 Gbit/s (18 X 2.5 Gbit/s)	Fiber Type:	Compliant With ITU-T G.652, G.653 And G.655
Wavelength:	Compliant With ITU-T G694.2	MTBF:	> 50 000 Hours/channel
OCH Protection:	1+1 Protection	OMS Protection:	1+1 Protection
Chassis:	1U

our business scope include Router/Switch/BRAS, GPON/EPON/FTTX, Optical TRANSMISSION(SDH/DWDM/PTN/Microwave), DSLAM/PSTN/MSAG/MSAN, Firewall/Security Gateway, Power Energy/UPS/indoor Outdoor Cabinet, Video Conference, WLAN etc., We also supply used and refurbished wireless and core network, including Huawei/Ericsson/ NSN/Alcatel/ZTE, GSM/UMTS/LTE, BBU, RRU, BTS.

Product Introduction

Product Appearance

The ZTE ZXMP M600

High integration
A CWU sub-rack (height: 1U) can be used to implement transmission of 4+1 wavelengths by building an optical terminal multiplexer (OTM) node. "+1" refers to the 1310 nm optical supervisory channel (OSC).
A CWU sub-rack (height: 1U) can implement bidirectional transmission of 3 wavelengths by building an optical add/drop multiplexer (OADM) node.
Flexible networking mode
Multiple networking modes, chain networking, ring networking and tangent networking, etc.
Modular architecture, it supports flexible adding/dropping from 1 to 18 wavelengths and smooth In-service upgrading.
Optional OSC/ESC
ZXMP M600 provides 4-degree OSC. It also provides ESC electrical supervision function.
Diversity access service type
ZXMP M600 can access any-rate-service (10Mb/s~2.7Gbit/s),
STM-0, STM-1, STM-4, STM-16.
E3, T3/DS3, E4, FE, GE, FC, 2G FC, ESCON, DVB-ASI.
2 x GE → 2.67Gbit/s
L2 switching
ZXMP M600 supports L2 switching function, SFE board can Multiplex 2 channels of GE signals and 8 channels of FE, which can save wavelengths tremendously.
Reliable protection
ZXMP M600 supports optical multiplex section (OMS) 1+1 protection, optical channel (OCH) 1+1 protection, and 1+1 protection inside board.
Convenient maintenance
Support universal slots and hot swapping of boards in CWU and CWE sub-rack except for the PCW and NCP board. SFP optical module is Replaceable.
Fan is front installation and hot plug in the sub-rack.
Flexible sub-rack design
CWU sub-rack has the height of 1U (44 mm) and 6 slots. It supports desktop installation or IEC/ETS standard cabinet installation in the front or back.
Multiple power supply modes
The CWU sub-rack supports power supply of -48V/-60V DC, or 220V (50 Hz)/110V (60 Hz) AC. An external adapter is needed for AC input.
Two 1+1 hot backup power supply modules guarantee the system reliability.

Product Specification

The ZTE ZXMP M600:

Item	Description
Application code	8-channel system (8+1 wavelengths)	Compliant with ITU-T G.695 Link model application code: S-C8L1-1D2/3/5 C8L1-1D2/3/5
	8-channel system (4+1 wavelengths)	Compliant with ITU-T G.695 Link model application code: C4L1-1D2/3/5
	18-channel system	Compliant with ITU-T G.695 Link model application code: C16L1-1D2 C16S1-1D2
Line budget	8-channel system	8+1 wavelengths point-to-point system	20 dB
			22 dB (1.25 Gbit/s signal)
		4+1 wavelengths point-to-point system	22 dB
			24 dB (1.25 Gbit/s signal)
	18-channel system	8+1 wavelengths point-to-point system	20 dB
			22 dB (1.25 Gbit/s signal)
		4+1 wavelengths point-to-point system	22 dB
			24 dB (1.25 Gbit/s signal)
		18 wavelengths Point-to-point system	19 dB
			21 dB (1.25 Gbit/s signal)
