Optical port : 1 x GPON interface (SC/APC)
Transmission Distance: 0 ~ 20km
Transmit rate: 2.488Gbps downstream; 1.244Gbps upstream
User Network Interface
4 x 10/100/1000Base-T; Half/full duplex; Auto MDI/MDIX; Auto negotiation
2 x POTS (VoIP) interfaces
Optical Module
Wavelength:
Receiving: 1480~1500 nm
Transmitting: 1290~1330 nm
Receiving Sensitivity: -28dBm
Transmitting Optical Power: 0.5~5dBm
Physical Performance
Power consumption: <7W
Dimensions: 180mm(W) x 38mm(H) x 127mm(D)
Working temperature: 0oC ~ 40oC
Working humidity: 5% ~ 95%
Weight: about 260g
Power supply: 12 V DC
Mounting mode: Desktop/Wall mounting
Supports hidden and coiled fiber
Backup battery: 3AH/6AH (Optional)
Main Function
Supported service: VoIP, Internet, IPTV
GPON: 8 T-CONTs, 32 GEM Ports
VLAN: 802.1Q, 802.1P, 802.1ad
MAC address table: 1k
L3 function: DHCP server/Client, DNS Client, NAT
IPv6: Dual Stack, DS-Lite
VoIP: SIP/H.248, G.711/G.722/G.729, T.30/T.38
Multicast: IGMP v1/v2 Snooping/Proxy, MLD v1 Snooping
Multicast group per user port: 256
QoS: service flow classification based on physical port, MAC address, VLAN ID, VLAN priority level, IP address; SP/WRR/SP+WRR
Management: local web management, OMCI, TR069
