WD2DLBBPD300 Huawei Wireless Network LBBPd1 LBBPd2 LBBPd4 LBBPd5 03021HPK

WD2DLBBPD300 Huawei Wireless Network LBBPd1 LBBPd2 LBBPd4 LBBPd5 03021HPK

  • WD2DLBBPD300 Huawei Wireless Network LBBPd1 LBBPd2 LBBPd4 LBBPd5 03021HPK
WD2DLBBPD300 Huawei Wireless Network LBBPd1 LBBPd2 LBBPd4 LBBPd5 03021HPK
Product Details:
Place of Origin: China
Brand Name: Huawei
Certification: CE FCC RoHS
Model Number: WD2DLBBPD300
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Export carton package
Delivery Time: 7-15 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 200 Piece/Pieces per Week
Contact Now
Detailed Product Description
Application: Base Station Wireless Network Product Series: Wireless
Warranty: 1 Year Condition: 100% Original Brand
High Light:

WD2DLBBPD300 Huawei Wireless Network


LBBPd1 Huawei Wireless Network


huawei WD2DLBBPD300

Huawei LBBPd3 WD2DLBBPD300 LBBPd1 LBBPd2 LBBPd4 LBBPd5 LBBPd6 LBBPc 03021HPK for Huawei BBU3900 BBU3910


Indoor Macro Base Station BTS3900

This indoor, dual-mode macro base station supports Huawei’s GSM-R 5.0, plus evolution to an eLTE broadband network. One of the most compact indoor macro base stations in the industry, it features large, scalable capacity in a small footprint, and multiple-mode applications that meet the requirements of long-distance railways.

The base station cabinet contains a maximum of six RF modules. In addition, its MRFU double-radio frequency units are important components of GSM-R and eLTE. Distributed base stations at the same sites reduce site deployment costs and customer investment.

Product Details


Huawei GSM-R Products

Base Station Sub-System


BTS3900 is a indoor macro BTS and BTS3900A is for outdoor. This base station features greater transmit power, higher reliability and LTE Evolution.

Frequency Band:
E-GSM: 880-915(35MHz)
ER-GSM 873-880(7 MHz)
Transmitting Diversity, 4-way Receiving Diversity
Top Power:
ER frequency band: 60W
E frequency band: 80W
Static receiving sensitivity: -112.5 dBm
Outdoor BTS3900A us of stronger acclimatization: -40℃~+50℃, IP55 protection lever



The DBS3900 GSM features a distributed architecture and consists of two basic fuction modules: BBU and RRU.
These basic modules can be flexibly configured to meet requurements for different capacities and in different application scenarios for GSM network.

Frequency 900M EGSM/ 900M RGSM
Sensitivity:-113dBm/1-Way Receiver -116 dBm/2-Way Receiver
TOC: 30W per TRX
Protection level: IP65
Temperature: -40℃~+50℃(without solar radiation)

Weight: 7 to 12KG
Capacity: 36 TRXs
Power Consumption: 50W
Protection level: IP20
Temperature: -20℃~+50℃


BSC6000 is responsible for radio resource management, base station management and power control.
Max equivalent BHCA: 5,900 k
Traffic volume: 24,000
Number of TRXs: 2,048
Number of configuren PDCHs: 30,720
Gb interface through put: 1,536 Mbit/s
Power consumption:≤3200W

Network Sub-System


The eCN300 depliys all CN NEs of GSM-R in single cabinet, including MSC Server, UMG and HLR based on the unified ATCA platform. Futhermore eCNS300 is evolution for LTE.
The typical configuaration is MSC Server, eHLR, and eUMG sharing one subrack.
Specification is:
Maximum subscribers: 50000
System Reliability:≥99.999%
Weight: ≤200KG
Power Consumption: ≤2200W(housing MSC server + eHLR + eUMG)


Huawei USN9810 is a unified service node that can be deployed in Evolved Packet Core(EPC) systems.
ATCA platform
Maximum subscribers: 12,000,000
Maximum bearers: 24,000,000
Number of eNodesBs: 50000
Number of S-GWs and P-GWs: 4096
Weight: <400KG (with full configuration)


The Huawei proprietary UGW9811(UGW9811) is a unified packet gateway that can be deployed in Evolved Packet Core(EPC) systems, it provides the functionalities of serving gateway(S-GW), PND gateway(P-GW).
Maximum bearers: 5,000,000(SPUs in active/standby mode)
Maximum data throughput: 120 Gbit/s(SPUs in active/standby mode)
Maximum APNs: 3,000
Maximum eNodeBs: 100,000
Weight: <380KG (with full configuration)
Dimensions:(H)2200mm x (W)600mm x (D)800 mm

Operation Support System

iManager U2000

The iManager U2000 centrally manages Huawei mobile network elements(NEs), including BSS and NSS. The U2000 provides basic functions, such as configuration management, performance management, fauly management, security management, log management, topology management, software managementm and system management. It also provides various optionak functions.
