Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.

Home ProductsHuawei Wireless Network

RRU5235E 02312JHH Frequency Band 1800MHz 2600MHz 4T4R 02312BYU 02312BYT

RRU5235E 02312JHH Frequency Band 1800MHz 2600MHz 4T4R 02312BYU 02312BYT

  • RRU5235E 02312JHH Frequency Band 1800MHz 2600MHz 4T4R 02312BYU 02312BYT
RRU5235E 02312JHH Frequency Band 1800MHz 2600MHz 4T4R 02312BYU 02312BYT
Product Details:
Place of Origin: China
Brand Name: Huawei
Certification: CE FCC RoHS
Model Number: RRU5235E
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Export carton package
Delivery Time: 7-15 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 200 Piece/Pieces per Week
Contact Now
Detailed Product Description
Model: RRU5235E Condition: 100% Original Brand
Warranty: 1 Year Weight: 10.5~20.5 Kg
Part Number: 02312JHJ, 02312JHH Part No.2: 02312BYU
Part No.3: 02312BYT Part No.4: 02312EGV
Part No.5: 02312EGW Part No.7: 02312HKV
Chipset: Original Application: Wireless Networking Sites
High Light:

1800MHz RRU5235E

,

2600MHz 02312JHH

,

02312BYU

Huawei 3600 Series Remote Radio Units RRU5235E 02312JHH Frequency Band 1800MHz 2600MHz 4T4R 02312BYU 02312BYT



RRU Functions:



The Remote Radio Unit (RRU) consists of the high-speed interface unit, signal processing unit, power amplifier, duplexer,
extension ports, and power module.



The RRU performs the following functions:

* Receives downlink baseband data from the BBU and sends uplink baseband data to the BBU.
* Receives RF signals from the antenna system, down-converts the signals to intermediate frequency (IF) signals, amplifies the IF signals, performs analog-to-digital conversion, and up-converts RF signals to the transmit (TX) band.
* Multiplexes receive (RX) and TX signals on the RF channel so that these signals can share the same antenna channel, and filters the RX and TX signals.
* Provides a built-in Bias Tee (BT). The built-in BT couples RF signals and OOK signals and transmits them through the TX/RX port A. The built-in BT also supplies power to the tower mounted amplifier (TMA).
* The RRU can work with the Monitoring Extension Box (MEB). The MEB can transmit external RS-485 communication signals and dry node monitoring signals into the RRU, implementing information monitoring and reporting.

* When an RRU is equipped with an AC/DC power module, the RRU and the power module together are called an AC RRU.

Packing

1. Original Carton Package.
2. As customers' requirement.

Delivery

1. 3-7 Working days after received the payment.
2. Shipment: Sea transportation & Air transportation ( DHL / UPS / TNT / Fedex / EMS )
