HUAWEI RTN300 series full-band microwave RTN380 IP microwave

Product Details:

Place of Origin:	China
Brand Name:	Huawei
Certification:	CE FCC RoHS
Model Number:	RTN380

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiable
Price:	Negotiable
Packaging Details:	Export carton package
Delivery Time:	7-15 days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	200 Piece/Pieces per Week

Contact Now

Detailed Product Description

Working Temperature:	-35℃~+55℃	Relative Humidity:	5%~100%
DC Power:	-38.4V ~ -57.6V

RTN300 series of new generation of outdoor IP microwave transmission system

Huawei RTN300 series, is a highly integrated full-outdoor microwave products. Including RTN310, RTN360, RTN380 three products. RTN300 series is the microwave equipment, all the features are integrated in an outdoor box, to achieve zero-site full outdoor installation;

The RTN310 is a full-band microwave in the conventional frequency range and requires the use of a conventional frequency band. The RTN360 is a V-band microwave, the RTN380 is an E-band microwave, and the E / V-band is a free band in most countries. Light-charged band. As a result, the RTN300 Series provides enterprise customers with a complete outdoor microwave transmission solution with low network costs and low operating costs.

	RTN310	RTN360	RTN380
Support frequency	13/15/18/23/38GHz	59-64GHz	71-86GHz
Channel spacing	7/14/28/56MHz	200MHz	62.5/125/250/500/750MHz
Modulation mode	QPSK Strong~2048QAM Light	160QAM	QPSK Strong~64 QAM
Throughput	2Gbps Max	400Mbps	4Gbps Max
Business interface	GE	GE	GE, CPRI interface
USB interface	Support	Support	Support
Working environment	Working temperature : -35℃~+55℃ Relative humidity: 5%~100%
Power supply range	Support Ethernet power supply; Support DC power : -38.4V ~ -57.6V
Weight	6kg	2.5kg	3.8kg

Features

1. Large bandwidth:

RTN310 support up to 2Gbps / carrier frequency large bandwidth, continuous expansion of the network worry;RTN360 support a single device 400Mbps transmission, close to zero-site deployment worry-free;RTN380 support a single device 4Gbps high-capacity transmission, to meet the backbone of large-capacity short-range return.

2. High reliability:

Support network-level, link-level, device-level multi-level protection; to meet the IP65 dustproof and waterproof 8KA mine grade requirements to ensure reliable operation in harsh environments in various fields.

3. Good luck:

Support engineers under the tower operation and maintenance, without climbing tower; support the deployment of USB configuration to enhance efficiency; support 360-degree automatic sweep, easy to select frequency.

Packing & Delivery
