Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | TNN1XMD2 |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| TNN1XMD2: | 2-channel Bidirectional Optical Add/drop Multiplexing Board |
|---|
The XMD2 is used to add/drop two channels of signals in a CWDM system.
Table 1 provides the functions and features of the XMD2.
| Function and Feature | XMD2 |
|---|---|
| Basic functions |
|
The technical specifications of the XMD2 include the parameters specified for optical interfaces, laser safety class, mechanical specifications, and power consumption.
Table 1 lists the parameters specified for the optical interfaces of the XMD2.
| Optical Interface | Parameter | Value |
|---|---|---|
| - | Operating wavelength range (nm) | 1260 to 1360, 1460 to 1620 |
| - | Channel spacing (nm) | 20 |
| IN1-D11 IN1-D12 IN2-D21 IN2-D22 | 1.0 dB passband bandwidth (nm) | ≥ 13.0 |
| Insertion loss (dB) on the drop channel | < 1.5 | |
| Adjacent channel isolation (dB) | > 30 | |
| Non-adjacent channel isolation (dB) | > 40 | |
| A11-OUT1 A12-OUT1 A21-OUT2 A22-OUT2 | 1.0 dB passband bandwidth (nm) | ≥ 13.0 |
| Insertion loss (dB) on the add channel | < 1.5 | |
| - | Reflectance (dB) | < -40 |
The safety class of the laser on the board is Class 1M. The maximum launched optical power of the optical interfaces is within the range from 10 dBm (10 mW) to 22.15 dBm (164 mW).
The mechanical specifications of the XMD2 are as follows:
The power consumption of the XMD2 at room temperature (25°C) is 0 W.
