Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | TNN1CO1 |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| TNN1CO1: | Eight-port Channelized STM-1 Interface Board |
|---|
The CO1 receives eight channels of channelized STM-1 CES services and works with the EG8 to process the received services.
Table 1 provides the functions and features of the CO1.
| Function and Feature | Description | |
|---|---|---|
| Basic functions | Provides eight channelized STM-1 optical interfaces and works with an EG8 board to process fractional E1 services and 64 kbit/s CES services. | |
| Interface types | Supports different types of standard optical interfaces, namely, S-1.1, L-1.1, and L-1.2 to meet requirements for transmission distances. The characteristics of the optical interfaces comply with ITU-T G.957. | |
| Interface characteristics | Automatic laser shutdown | Not supported. |
| Loopback types of the port | Inloops and outloops at STM-1 ports Inloops and outloops on VC-12 paths | |
| Auto disabling of port loopback | Supported. | |
| Detection and query of optical module information | Supported. | |
| Pluggable optical module | Supports SFP optical modules. | |
| CES | Number of supported CES services | 504 |
| Supported emulation mode | CESoPSN SAToP | |
| Timeslot compression | Supported. | |
| Jitter compensation buffering time | 0.375 ms to 16 ms, in increments of 0.125 ms | |
| Packet loading time | 0.25 ms to 5 ms, in increments of 0.125 ms | |
| Protection scheme | Packet-based linear MSP | 1+1 |
| 1:1 | ||
| SSM protocol | Supported. | |
| PRBS | Not supported | |
| Query of laser transmission distance | Supported | |
The technical specifications of the CO1 include the parameters specified for optical interfaces, laser safety class, mechanical specifications, and power consumption.
Table 1 lists the parameters specified for the optical interfaces of the CO1.
| Port type | Description |
|---|---|
| S-1.1 | 15 km STM-1 two-fiber bidirectional optical interfaces |
| L-1.1 | 40 km STM-1 two-fiber bidirectional optical interfaces |
| L-1.2 | 80 km STM-1 two-fiber bidirectional optical interfaces |
The safety class of the laser on the board is Class 1. The maximum launched optical power of the optical interfaces is less than 10 dBm (10 mW).
The mechanical specifications of the CO1 are as follows:
The maximum power consumption of the CO1 at room temperature (25°C) is 17 W.
