Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | TNN1ETMC |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| TNN1ETMC: | 8xFE+4xFE/GE Electrical Interface Board |
|---|
ETMC boards provide four FE/GE auto-sensing electrical ports and eight FE electrical ports to receive Ethernet services, and work with the EG8 to process the received Ethernet services.
Table 1 lists the functions and features supported by ETMC boards.
| Function and Feature | Description | |
|---|---|---|
| Basic functions | Provides eight FE fixed electrical ports and four GE/FE adaptive electrical ports to transmit/receive 12xFE or 4xGE electrical signals. NOTE: If both FE and GE electrical ports are used, the total bandwidth cannot exceed 2GE. The boards in slots 1, 3, 5, 7, 9, and 11 share 1 Gbit/s bandwidth, and the boards in slots 2, 4, 6, 8, 10, and 12 share 1Gbit/s bandwidth. | |
| Port types | Supports 1000BASE-T and 100BASE-TX Ethernet electrical ports, which use RJ45 connectors and comply with IEEE 802.3u. | |
| Port characteristics | Pluggable optical module | Not supported |
| Single-fiber bidirectional optical module | Not supported | |
| Working modes | GE electrical ports: 100M half-duplex, 100M full-duplex, 1000M full-duplex, and auto-negotiation FE electrical ports: 100M half-duplex, 100M full-duplex, and auto-negotiation | |
| Flow control at ports | Auto-negotiation mode: not supported | |
| Non-autonegotiation mode: not supported | ||
| Query/Setting of port status | Supported | |
| Query of port types | Supported | |
| Query/Setting of unidirectional-mode | Not supported | |
| Service specifications | Service bearing modes | MPLS: supported |
| QinQ: supported | ||
| Port: supported | ||
| MFL for ports | Supports the setting of the packet length, which ranges from 960 bytes to 4600 bytes. After the setting becomes valid, the length of the packets that enter or exit the ports is restricted by the preset MFL. | |
| MTU for services | Ranges from 64 to 9600 bytes, with the default value of 1500. | |
| Ethernet service capability | E-Line service: supported | |
| E-LAN service: supported | ||
| E-AGGR service: not supported | ||
| Jumbo frame | Supports a jumbo frame with a length not more than 4600 bytes. | |
| MS-PW | Supports static switching of MS-PWs. | |
| Protection schemes | Tunnel APS | 1+1 (single-ended/dual-ended) and 1:1 (dual-ended) in compliance with ITU-T Y.1720 and ITU-T G.8131. |
| PW APS | 1+1 (single-ended/dual-ended), 1:1 (dual-ended), and PW FPS (single-ended) in compliance with ITU-T Y.1720 and ITU-T G.8131. | |
| MRPS | Supports MRPS.
| |
| LAG | Supported | |
| MC-LAG | Supported | |
| MSTP | Supported | |
| LPT for packet services | Point-to-point LPT: supported | |
| Point-to-multipoint LPT: supported | ||
| Synchronization | Synchronous Ethernet | Supports 12 synchronous Ethernet clocks. |
| IEEE 1588v2 | Supports 12 IEEE 1588v2 time synchronization and clock synchronization. | |
| Maintenance features | ETH OAM | Ethernet Service OAMa: Supports CC, LB and LT. These functions comply with IEEE 802.1ag. |
| Ethernet Port OAMa: Supports OAM auto-discovery, fault detection, link performance monitoring, and self-loop test. These functions comply with IEEE 802.3ah. | ||
| Distributed MPLS OAM/Centralized MPLS OAM | MPLS tunnel OAMa: Supports CV, FFD, Tunnel ping, and Tunnel traceroute. These functions comply with ITU-T Y.1711. | |
| MPLS PW OAMa: Supports CV, FFD, PW ping, and PW traceroute. These functions comply with ITU-T Y.1711. | ||
| MPLS-TP OAM | MPLS-TP tunnel OAMa: Supports CC, RDI, AIS, LB, LT, LM, 1DM, TST, LCK, and 2DM. These functions comply with ITU-T G.8113.1. | |
| MPLS-TP PW OAMa: Supports CC, RDI, AIS, LB, LT, LM, 1DM, TST, LCK, CSF, and 2DM. These functions comply with ITU-T G.8113.1. | ||
| Loopback capability | PHY layer at Ethernet ports:
| |
| MAC layer at Ethernet ports: supports inloops and outloops. | ||
| RMON | Supported | |
| Port Mirroring | Supported | |
| Inband DCN | Supported | |
| LLDP | Supported | |
| HQoS | Supports service WRED policies, port WRED policies, WFQ policies, PW polices, QinQ polices, V-UNI ingress policies, V-UNI egress policies, port policies, port shaping. | |
| IGMP Snooping | Supported | |
| Query of electronic labels | Supported | |
The technical specifications of the ETMC include the parameters specified for electrical interfaces, mechanical specifications, and power consumption.
Table 1 lists the parameters specified for the electrical interfaces of the ETMC.
| Port type | Description |
|---|---|
| FE electrical interfaces | FE electrical interfaces (RJ-45/Packet)
|
| GE electrical interfaces | GE electrical interfaces FE/GE1 to FE/GE4: 100 Mbit/s and 1000 Mbit/s, adaptive |
The mechanical specifications of the ETMC are as follows:
The maximum power consumption of the ETMC at room temperature (25°C) is 11 W.
