Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | TNN1EX2 |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| TNN1EX2: | 2x10GE Processing Board |
|---|
EX2 boards process and forward 2x10GE services and support QoS functions such as traffic management, congestion control, and scheduling.
Table 1 lists the functions and features supported by EX2 boards.
| Function and Feature | Description | |
|---|---|---|
| Basic functions | Provides two 10GE optical ports to transmit/receive and process 2x10GE services. | |
| Port types |
| |
| Functions when being used with an interface board | Provides ports on the front panel. | |
| Port characteristics | Pluggable optical module | Supports XFP optical modules. |
| Single-fiber bidirectional optical module | Not supported | |
| Working modes | 10GE full-duplex (only in LAN mode) | |
| Flow control at ports | Auto-negotiation mode: not supported | |
| Non-autonegotiation mode: supported | ||
| Query/Setting of port status | Supported | |
| Query of port types | Supported | |
| Query/Setting of optical power thresholds | The setting of input optical power thresholds is supported. | |
| Query/Setting of unidirectional-mode | Supported | |
| Service specifications | Processing capability | 20 Gbit/s in full-duplex mode |
| Service bearing modes | MPLS: supported | |
| QinQ: supported | ||
| Port: supported | ||
| PW specifications | Maximum number of PWs: supports 16K bidirectional static PWs. | |
| Maximum number of MS-PWs: 8K | ||
| Tunnel specifications | Number of unidirectional MPLS tunnels (with tunnels shared): 16K | |
| Number of bidirectional MPLS tunnels (with tunnels shared): 8K | ||
| MFL for ports | Supports the setting of the packet length, which ranges from 960 bytes to 9600 bytes. After the setting becomes valid, the length of the packets that enter or exit the ports is restricted by the preset MFL. | |
| MTU for services | For packet services carried by PWs, EX2 boards support the setting of the packet length, which ranges from 64 bytes to 9600 bytes. For packet services carried in other modes, EX2 boards do not support the setting of the packet length. | |
| Ethernet service types | E-Line service: supported Number of supported E-Line services: 8K | |
| E-LAN service: supported Number of supported E-LAN services: 1K Number of static MAC addresses in E-LAN services: 2K | ||
| E-AGGR service: not supported | ||
| Formats of Ethernet data frames | Supports the encapsulation in IEEE 802.3 format, Ethernet II format, or IEEE 802.1q/p format. | |
| Maximum number of QinQ links | 4K | |
| Jumbo frame | A maximum length of 9600 bytes | |
| Protection schemes | Tunnel APS | Supports the 1+1 (single-ended/dual-ended) and 1:1 (dual-ended) tunnel APS in compliance with ITU-T Y.1720 and ITU-T G.8131. Number of supported tunnel APS protection groups: 1K |
| PW APS | Supports the PW FPS (single-ended), 1+1 (single-ended/dual-ended) and 1:1 (dual-ended) PW APS in compliance with ITU-T Y.1720 and ITU-T G.8131. Supports a maximum of 1K PW APS protection groups, and a PW protection group can bind a maximum of 512 members. | |
| MRPS | Supports MRPS.
| |
| LAG |
| |
| MC-LAG | Supported, which complies with IEEE 802.3ad and IEEE 802.1AX. | |
| MSTP | Supported, which complies with IEEE 802.1s. | |
| LPT | Point-to-point LPT: supported | |
| Point-to-multipoint LPT: supported | ||
| Synchronization | Synchronous Ethernet Clock | Supports two synchronous Ethernet clocks. |
| 1588v2 | Supports two IEEE 1588v2 time synchronization and clock synchronization. | |
| Maintenance features | ETH OAM | Ethernet Service OAMa: Supports CC, LB and LT. These functions comply with IEEE 802.1ag. Supports LM and 2DM. These functions comply with ITU-T Y.1731. Number of services that support Ethernet OAM (ETH OAM): 2K |
| Ethernet Port OAMa: Supports OAM auto-discovery, fault detection, and link performance monitoring. These functions comply with IEEE 802.3ah. Number of ports that support ETH OAM: 2K | ||
| Distributed MPLS OAM/Centralized MPLS OAM | MPLS tunnel OAMa: Supports CV, FFD, BDI, FDI, Tunnel ping, and Tunnel traceroute. These functions comply with ITU-T Y.1711. Number of MPLS tunnels that support OAM: 2K | |
| MPLS PW OAMa: Supports CV, FFD, BDI, FDI, PW ping and PW traceroute. These functions comply with ITU-T Y.1711. Number of MPLS PWs that support OAM: 2K | ||
| MPLS-TP OAM | MPLS-TP tunnel OAMa: Supports CC, RDI, AIS, LB, LT, LM, 1DM, TST, LCK, and 2DM. These functions comply with ITU-T G.8113.1. Number of tunnels that support MPLS-TP OAM: 2K | |
| MPLS-TP PW OAMa: Supports CC, RDI, AIS, LB, LT, LM, 1DM, TST, LCK, CSF, and 2DM. These functions comply with ITU-T G.8113.1. Number of PWs that support MPLS-TP OAM: 2K | ||
| Loopback capability | PHY layer at Ethernet ports: not supported | |
| MAC layer at Ethernet ports: supports inloops and outloops. | ||
| RMON | Supported | |
| Port Mirroring | Supported | |
| Inband DCN | Supported | |
| LLDP | Supported | |
| HQoS | Supports service WRED policies, port WRED policies, WFQ policies, PW polices, QinQ polices, V-UNI ingress policies, V-UNI egress policies, port policies, port shaping. | |
| IGMP Snooping | Protocol enabling | Supported |
| Port aging time | Supported | |
| Fast leave | Supported | |
| Discarding of unknown broadcast packets | Supported | |
| Static broadcast entry | Supported | |
| Query of electronic labels | Supported | |
| NOTE: a: MPLS tunnel OAM, MPLS PW OAM, MPLS-TP tunnel OAM, MPLS-TP PW OAM, and ETH OAM share OAM resources. | ||
The technical specifications of the EX2 include the parameters specified for optical interfaces, laser safety class, mechanical specifications, and power consumption.
Table 1 lists the parameters specified for the optical interfaces of the EX2.
| Port type | Description |
|---|---|
| 10GBASE-LR (LAN) | 10 km 10GE two-fiber bidirectional optical interfaces |
| 10GBASE-ER (LAN) | 40 km 10GE two-fiber bidirectional optical interfaces |
| 10GBASE-ZR (LAN) | 80 km 10GE two-fiber bidirectional optical interfaces |
| 70 km CWDM | 70 km 10GE CWDM optical interfaces |
| 40 km DWDM | 40 km 10GE DWDM optical interfaces |
| 80 km DWDM | 80 km 10GE DWDM optical interfaces |
The safety class of the laser on the board is Class 1. The maximum launched optical power of the optical interfaces is less than 10 dBm (10 mW).
The mechanical specifications of the EX2 are as follows:
The maximum power consumption of the EX2 at room temperature (25°C) is 60 W.
