Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | SSN2DCU07 |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| SSN2DCU07: | Compensated Dispersion For Dual Channels: 40 Km/60 Km |
|---|
The DCU can compensate for the dispersion for a maximum of two channels of optical signals. The DCU can be used with the BA and PA.
Table 1 provides the functions and features of the DCU.
| Function and Feature | N1DCU | N2DCU |
|---|---|---|
| Basic functions | Compensates for the dispersion of a maximum of two channels of optical signals at the same time. Supports the compensated dispersion of 1020 ps/nm (for the dispersion caused by the 60 km G.652 optical fiber), 1360 ps/nm (for the dispersion caused by the 80 km G.652 optical fiber), or any combination. | Compensates for the dispersion of a maximum of two channels of optical signals at the same time. Supports the compensated dispersion of 680 ps/nm (for the dispersion caused by the 40 km G.652 optical fiber), 1020 ps/nm (for the dispersion caused by the 60 km G.652 optical fiber), 1360 ps/nm (for the dispersion caused by the 80 km G.652 optical fiber), or any combination. |
| Dispersion compensation method | Compensates for the dispersion accumulated during the transmission by using the chirp grating and suppresses the pulse signals to restore the optical signals. | |
| Long haul transmission with optical regeneration | Realizes long haul transmission with optical regeneration when working with the BA and PA. | |
The technical specifications of the DCU include the parameters specified for optical interfaces, mechanical specifications, and power consumption.
Table 1 lists the parameters specified for the optical interfaces of the DCU.
| Parameter | Value |
|---|---|
| Nominal bit rate | 9953280 kbit/s |
| Line code pattern | NRZ |
| Central wavelength (nm) | 1550.12±0.05 |
| -0.5 dB bandwidth (nm) | > 0.4 |
| Compensated dispersion (ps/nm) | N1DCU: 1020 (60 km); 1360 (80 km) N2DCU: 680 (40 km); 1020 (60 km); 1360 (80 km) |
| Insertion loss (dB) | Less than 8.3 dB in the case of the N1DCU and less than 3 dB in the case of the N2DCU |
The mechanical specifications of the DCU are as follows:
The maximum power consumption of the DCU at room temperature (25°C) is 0 W.
