| SSN1EAS2: | 2-port 10xGE Switching And Processing Board |
|---|
EAS2 boards support the transmission of 10 GE Ethernet services, LCAS, and test frame functions.
Table 1 lists the functions and features supported by EAS2 boards.
| Function and Feature | Description | ||
|---|---|---|---|
| Basic functions | Receives/Transmits 2x10 GE Ethernet services. | ||
| Port types | Supports 10GBASE-LR and 10GBASE-LW Ethernet optical ports, which comply with IEEE 802.3ae. | ||
| Functions when being used with an interface board | Provides ports on the front panel. | ||
| Port characteristics | Working mode | 10GE full-duplex in both WAN mode and LAN mode | |
| Traffic control mode at ports | Auto-negotiation mode | Not supported | |
| Non-autonegotiation mode | Supported | ||
| Query/Setting of port status | Supported | ||
| Query of port types | Supported | ||
| Setting of optical power thresholds | Not supported | ||
| Pluggable optical module | XFP optical modules supported on N1EAS2 boards SFP+ optical modules supported on N3EAS2 boards N3EAS2 supports one-fiber bidirectional optical modules. | ||
| Service categories | Ethernet private line (EPL) service | Supports PORT-based transparent transmission. | |
| Ethernet virtual private line (EVPL) service |
| ||
| Ethernet private LAN (EPLAN) service |
| ||
| Ethernet virtual private LAN (EVPLAN) service |
| ||
| Service specifications | Formats of Ethernet data frames | IEEE 802.3 | Supported |
| Ethernet II | Supported | ||
| IEEE 802.1 q/p | Supported | ||
| Frame length range |
| ||
| Concatenation granularities | The following adjacent concatenation granularities are supported on N1EAS2 boards: VC-4-Xv (X≤8), VC-3-Xv (X≤24), and VC-4-4c. The following adjacent concatenation granularities are supported on N3EAS2 boards: VC-4-Xv (X≤64) and VC-4-4c/16c/64c. NOTE: For N3EAS2 boards, VCTRUNK1 and VCTRUNK18 support VC-4-16c/64c adjacent concatenation. Other VCTRUNKs only support VC-4-4c adjacent concatenation. N3EAS2 boards support adjacent concatenation only for bidirectional services. | ||
| Encapsulation formats | HDLC | Not supported | |
| LAPS | Not supported | ||
| GFP-F | Supported | ||
| MPLS technology | Not supported on N1EAS2 boards Tunnel-based EVPL (transit) supported on N3EAS2 boards | ||
| VLAN technology | Supports a total number of 4094 VLANs, which comply with IEEE 802.1q/p. | ||
| Maximum uplink bandwidth | An N1EAS2 board supports a maximum of 10 Gbit/s upstream bandwidth and can adapt to the bandwidth of its slot. An N3EAS2 board supports a maximum of 20 Gbit/s upstream bandwidth and can adapt to the bandwidth of its slot. | ||
| Maximum bound bandwidth | N1EAS2: 64xVC-4 or 192xVC-3 N3EAS2: 128xVC-4 | ||
| VCTRUNK specifications | An N1EAS2 board supports a maximum of 24 VCTRUNKs. Configuration guidelines are as follows:
The maximum number of VCTRUNKs supported by the N3EAS2 board is as follows:
Configuration guidelines are as follows:
| ||
| Protection schemes | TPS | Not supported | |
| BPS | Not supported | ||
| PPS | Not supported | ||
| DLAG | Supported | ||
| LAG | Supports manual link aggregation and static link aggregation. Supports the load sharing mode and load non-sharing mode. Complies with IEEE 802.3ad and IEEE 802.1AX. | ||
| LCAS | Supports LCAS, which dynamically increases or decreases the bandwidth and protects the bandwidth in compliance with ITU-T G.7042. | ||
| LPT | Supports P2P LPT and P2MP LPT in compliance with proprietary protocol. | ||
| STP/RSTP | Supports the broadcast packet suppression function and RSTP, which comply with IEEE 802.1w. | ||
| MSTP | Not supported on N1EAS2 boards Supported on N3EAS2 boards | ||
| Ethernet ring protection switching (ERPS) | Not supported on N1EAS2 boards Supported on N3EAS2 boards NOTE: ERPS does not support the following bridges:
| ||
| Synchronization | Synchronous Ethernet | Not supported | |
| IEEE 1588v2 | Not supported | ||
| Maintenance features | ETH OAM |
| |
| Test Frame | Supports test frames in ETH and GFP bearer modes. | ||
| Response to ping | Supported | ||
| Port Mirroring | Supports ingress and egress mirroring. | ||
| Loopback capability | PHY layer at Ethernet ports | Supports inloops. | |
| MAC layer at Ethernet ports | Supports inloops. | ||
| VC-4 level | Not supported | ||
| VC-3 level | Not supported | ||
| VC-12 level | Not supported | ||
| RMON |
| ||
| Warm resets | Supported (Warm resets do not affect services.) | ||
| Cold resets | Supported | ||
| Alarms and performance events | Reports various alarms and performance events, which facilitates the management and maintenance of the equipment. | ||
| QoS |
| ||
| IGMP Snooping | Protocol enabling | Supported | |
| Port aging time | Supported | ||
| Fast leave | Not supported | ||
| Discarding of unknown broadcast packets | Not supported | ||
| Static broadcast entry | Supported | ||
| Hub/Spoke | Supported | ||
| Traffic control | Supports the port-based traffic control function that complies with IEEE 802.3x. NOTE: Only EPL services support port-based traffic control. | ||
The mechanical specifications of the EAS2 board are as follows:
The maximum power consumption of the N1EAS2 is 70 W at room temperature (25°C).
The maximum power consumption of the N3EAS2 is 83 W at room temperature (25°C).
