Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | SSN1EGSH11 |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| SSN1EGSH11: | 1000BASE-LX (10 Km) |
|---|
The EGSH supports the transmission of various Ethernet services, and performs Layer 2 switching, link aggregation, and multicast functions.
Table 1 provides the functions and features of the EGSH.
| Function and Feature | Description | ||
|---|---|---|---|
| Basic functions | The board processes 16xGE services. It provides functions such as O/E conversion, Ethernet frame processing, mapping, Layer 2 (L2) switching signals. The board is connected to the active and standby cross-connect boards through the backplane. In this manner, data is exchanged and services are scheduled. | ||
| Interface types |
| ||
| Functions when being used with an interface board | Transmits/Receives 16 channels of Ethernet signals through the interfaces on the front panel. | ||
| Interface characteristics | Working modes | Auto-negotiation, 1000M full-duplex | |
| Traffic control mode at ports | Auto-negotiation mode | Supported. | |
| Non-autonegotiation mode | Supported. | ||
| Query/Setting of port status | Supported. | ||
| Query of interface types | Supported. | ||
| Setting of optical power thresholds | Not supported. | ||
| Pluggable optical module | SFP optical modules | ||
| Service categories | EPL service | Supports the PORT-based transparent transmission. | |
| EVPL service |
| ||
| EPLAN service |
| ||
| EVPLAN service |
| ||
| Service specifications | Formats of Ethernet data frames | IEEE 802.3 | Supported. |
| Ethernet II | Supported. | ||
| IEEE 802.1 q TAG | Supported. | ||
| Frame length range | The 16 physical ports support a packet length ranging from 1518 bytes to 9600 bytes and a jumbo frame with a maximum length of 9600 bytes. The jumbo frame length supported by the 24 VCTRUNKs is as follows:
| ||
| Mapping granularities | Supports VC-4, VC-3, VC-4-Xv (X≤8), and VC-3-Xv (X≤24) granularities. | ||
| Encapsulation formats | HDLC | Not supported. | |
| LAPS | Not supported. | ||
| GFP-F | Supported. | ||
| MPLS technology | Not supported. | ||
| VLAN technology | Supports a total number of 4094 VLANs, which comply with IEEE 802.1q/p. | ||
| Maximum uplink bandwidth | The maximum uplink bandwidth of the EGSH is 10 Gbit/s. | ||
| Maximum bound bandwidth | 64 x VC-4, or 192 x VC-3 | ||
| VCTRUNK specifications | Number of supported VCTRUNKs: 24 Configuration principles are as follows:
| ||
| Protection schemes | TPS | Not supported. | |
| BPS | Not supported. | ||
| PPS | Not supported. | ||
| DLAG | Supported. | ||
| LAG | Supports manual link aggregation and static link aggregation. Supports the load sharing mode and load non-sharing mode. Complies with IEEE 802.3ad and IEEE 802.1AX. | ||
| LCAS | Supports LCAS, which dynamically increases or decreases the bandwidth and protects the bandwidth in compliance with ITU-T G.7042. | ||
| LPT |
| ||
| STP/RSTP | Supports the broadcast packet suppression function and rapid spanning tree protocol (RSTP) that comply with IEEE 802.1w. | ||
| MSTP | Supported. | ||
| Clock synchronization | Synchronous Ethernet | Not supported. | |
| IEEE 1588v2 | Not supported. | ||
| Interconnection requirement | If the clocks are not synchronized between the source and sink NEs on the network, the service latency on the N1EGSH board may increase unexpectedly, which may affect performance and user experience of latency-sensitive services. | ||
| Maintenance features | ETH OAM |
| |
| Test frame | Supports test frames in GFP or Ethernet bearer mode. | ||
| Response to ping | Not supported. | ||
| Port Mirroring | Supported. | ||
| Loopback capability | PHY layer at Ethernet ports | Supports inloops. | |
| MAC layer at Ethernet ports | Supports inloops. | ||
| VC-4 level | Not supported. | ||
| VC-3 level | Not supported. | ||
| VC-12 level | Not supported. | ||
| Ethernet performance monitoring (RMON) | Supports RMON of the Ethernet performance of Ethernet ports and VCTRUNKs. | ||
| Warm resets | Supported (Warm resets do not affect services.) | ||
| Cold resets | Supported | ||
| Alarms and performance events | Reports various alarms and performance events, which facilitates the management and maintenance of the equipment. | ||
| QoS |
| ||
| IGMP Snooping | Protocol enabling | Supported | |
| Port aging time | Supported | ||
| Fast leave | Not supported | ||
| Discarding of unknown broadcast packets | Not supported | ||
| Static broadcast entry | Supported | ||
| Hub/Spoke | Supported | ||
| Traffic control | Supports the port-based traffic control function that complies with IEEE 802.3x. NOTE: Only EPL services support port-based traffic control. | ||
The mechanical specifications of the EGSH are as follows:
The maximum power consumption of the EGSH at room temperature (25°C) is 85 W.
