Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | SSN1EFT8A |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| SSN1EFT8A: | 8xFE Transparent Transmission Board |
|---|
EFT8A boards support the transparent transmission of Ethernet services, LCAS function, and test frames.
Table 1 lists the functions and features supported by EFT8A boards.
| Function and Feature | Description | ||
|---|---|---|---|
| Basic functions | Transparently transmits 8xFE services. | ||
| Port types |
| ||
| Functions when being used with an interface board | Provides ports on the front panel to receive/transmit 8xFE signals. | ||
| Port characteristics | Working modes | 100M full-duplex, 10M full-duplex, and auto-negotiation | |
| Traffic control mode at ports | Auto-negotiation mode | Not supported | |
| Non-autonegotiation mode | Supported | ||
| Query/Setting of port status | Supported | ||
| Query of port types | Supported | ||
| Setting of optical power thresholds | Not supported | ||
| Pluggable optical module | Not supported | ||
| Service categories | EPL service | Supports PORT-based transparent transmission. | |
| Service specifications | Formats of Ethernet data frames | IEEE 802.3 | Supported |
| Ethernet II | Supported | ||
| IEEE 802.1q TAG | Supported | ||
| Frame length range |
| ||
| Concatenation granularities | Supports VC-12, VC-3, VC-12-Xv (X ≤ 63), and VC-3-Xv (X ≤ 3) granularities. | ||
| Encapsulation formats | HDLC | Supported | |
| LAPS | Supported | ||
| GFP-F | Supported | ||
| MPLS technology | Not supported | ||
| VLAN technology | Supports VLAN transparent transmission. | ||
| Maximum uplink bandwidth | 622 Mbit/s | ||
| Maximum bound bandwidth | 12xVC-3, or 63xVC-12 + 9xVC-3 | ||
| VCTRUNK specifications | Number of supported VCTRUNKs: 8 Configuration principles are as follows:
| ||
| Protection schemes | TPS | Not supported | |
| LCAS | Supports LCAS, which dynamically increases or decreases the bandwidth and protects the bandwidth in compliance with ITU-T G.7042. | ||
| LPT | Supports P2P LPT in compliance with ITU-T G.7042. | ||
| LAG | Not supported | ||
| Clock synchronization | Synchronous Ethernet | Not supported | |
| IEEE 1588v2 | Not supported | ||
| Maintenance features | ETH OAM | Not supported by N1EFT8A boards N2EFT8A boards support CC, LB, and LT. These functions comply with IEEE 802.1ag. N2EFT8A boards support OAM auto-discovery, link performance monitoring, fault detection, remote loopback tests, and self-loop tests. These functions comply with IEEE 802.3ah. | |
| Test Frame | Supports test frames in GFP bearer mode. | ||
| Response to ping | Not supported | ||
| Port Mirroring | Not supported | ||
| Loopback capability | PHY layer at Ethernet ports | Supports inloops. | |
| MAC layer at Ethernet ports | Supports inloops. | ||
| VC-4 level | Not supported | ||
| VC-3 level | Supports inloops and outloops. | ||
| VC-12 level | Not supported | ||
| RMON | Supports Ethernet performance monitoring at the port level. | ||
| Warm resets | Supported (Warm resets do not affect services.) | ||
| Cold resets | Supported | ||
| Alarms and performance events | Reports various alarms and performance events, which facilitates the management and maintenance of the equipment. | ||
| QoS | Not supported | ||
| Hub/Spoke | Not supported | ||
| Traffic control | Supports the FE port-based traffic control function that complies with IEEE 802.3x. NOTE: Only EPL services support port-based traffic control. | ||
The mechanical specifications of the EFT8A are as follows:
The maximum power consumption of the EFT8A at room temperature (25°C) is 26 W.
