Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | ZTE C300 GTTO |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| Product Name: | ZTE C300 OLT GTTO | Application: | FTTH FTTB FTTX FTTC Network Access Equiment |
|---|---|---|---|
| Name: | C300 GTTO | Type: | Combo Card |
| Port: | Shenzhen |
ZXA10 C300 is aconvergent optical-access platform with large capacity and high density. Numerous access approaches are supported and the triple-play services can be realized. The customized scenarios are provided for various networks demands. ZXA10 C300 won the InfoVision Green Broadband Award at Broadband World Forum Europe (BBWF Europe) in 2010.
ZTE ZXA10 C300 configuration:
2 SCXM control board; (SCXL For Option)
1 GPON or EPON 8 ports board with 8 Modules; (GTGH ETGH16Ports for Option)
2 GUFQ board(4SFP Slot), 2 uplink modules on each;(HUTQ( 10G Uplink) GUSQ(2SFP Slot & 2RJ 45 GE Ports) Board for Optioin)
2 PRWG power boards; (AC to DC Power Converter have to buy separate)
2 Power cables
1 RJ-45 first turn 9-pin RS-232 female network cable
1 RJ-45 Network cable
1 Earth Cable
ZTE OLT ZXA10 C300 Card/Board SCXLSCXM SCXN SCXLMWIA GTGO PRWG CICG GUFQ GUSQ HUTQ XUTQ GDFO CTBB CTTB CTLA GPON / XGPON1 / P2P
| Configurations Options for ZXA10 C300 | |
| GPON / EPON OLT ZXA10 C300 10U with 14 Slot for Pon Board | |
| Configuration options | |
| ZXA10 C300 | Chassis+Fan+2*SCXM(or SCXN)+2*PRWG+GUFQ; accessories |
| ZXA10 C300 | Chassis+Fan+2*SCXM(or SCXN)+2*PRWG+2*GUFQ; accessories |
| ZXA10 C300 | Chassis+Fan+2*SCXM(or SCXN)+2*PRWG+HUTQ(or HUVQ); accessories |
| ZXA10 C300 | Chassis+Fan+2*SCXM(or SCXN)+2*PRWG+2*HUTQ(or HUVQ); accessories |
| ZXA10 C300 | Chassis+Fan+2*SCXM(or SCXN)+2*PRWG+HUTQ(or HUVQ)+GUFQ; accessories |
| ZTE OLT Option Part | |
| GTGO | 8 ports GPON board with 8 B+ modules. |
| GTGO | 8 ports GPON board with 8 C+ modules. |
| GTGO | 8 ports GPON board with 8 C++ modules. |
| GTGH | 16 ports GPON board with 16 B+ modules. |
| GTGH | 16 ports GPON board with 16 C+ modules. |
| GTGH | 16 ports GPON board with 16 C++ modules. |
| GTTO | 8 ports 10G GPON board with 8 10G GPON modules |
| GTXO | 8 ports 10G GPON board with 8 10G GPON modules |
| ETGO | 8 ports EPON board with 8 modules. |
| ETGH | 16 ports EPON board with 16 modules |
| ETTO | 8 ports 10G EPON board with 8 10G EPON modules |
| GUSQ | 2*GE optical + 2*GE/FE RJ45 uplink card |
| GUFQ | 4*GE/FE optical interface Ethernet uplink card |
| HUTQ/HUVQ | 2 ports 10GE and 2 ports GE optical interface Ethernet uplink card |
| SMXA/1 | Tri-functional card for C320 , the switching, control card & GE uplink |
| SMXA/3 | Tri-functional card for C320 , the switching, control card & 10GE uplink |
Uplink Interface
| GE | Single board: 4*GE(4 optical) |
| 4*GE(4 electric) | |
| 2*GE(optical)+2*10M/100M/1000M(electric) | |
| Chassis:8*GE, MAX 136*GE | |
| 10GE | Per board: 4*10GE(optical). Chassis:8*10GE |
User Interface
| P2P | Per board: 16*FE or GE. Chassis: 16 services slots, 256*FE/GE |
Return Material Authorization (RMA) Process
Standard Hardware Warranty Policy:
Original new sealed ZTE product: 1 Year
The Support Contacts:
If your ZTE products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.
Cargo will be delivered within 1 day after payment arrived. Tracking Number will be offered once delivery done.
Uonel is one of the biggest Huawei Network Hardware distributor in china, founded in 2008. We are a global provider of netwotking products with more than 5000 customers.
We provide original new Huawei Routers,Switches,Firewalls,Wireless APs & controllers,OLTs,GPON modems,optical transceivers.Our company have more than $5million Huawei products in stock.
Most of our technical engineers had work exprience in Huawei company,we can provide network design&planning,configration,troubleshooting,maintenance and training service in world wide.
