With the requirements of communication services increasing, the value-added services (VAS) including 3D network games, video conference/phone, Video on Demand (VoD) and IPTV are key means for operators toprovide differential services to attract more subscribers, and gain income growth.

        ZTE ZXA10 C320, a small size, full-service optical access convergent platform, provides carrier class QoS and reliable network to meet the requirements for small-scale implementation of FTTx services.

Unified platform for GPON,XG-PON1 and P2P:

* Small size and compact design, flexible network and fast deployment

* 2U frame with 2 service slots, compatible with ZXA10 C300 line cards

* Abundant service support capability: IPTV, VoIP, HSI, VPN, mobile backhaul, etc

* Higher security assurance: ONT authentication, user ID identification, port isolation, address binding, packet filtering, and broadcast packet suppression.

* High reliability: key parts redundancy; support Type B and Type C protection for PON downlink and LACP/ UAPS/STP/ERPS for uplink

* Service differentiation: Comprehensive QoS mechanisms for voice, video and high speed Internet services.

* Support DC input redundancy

* Support AC power supply

* Support 1:1 protection for PON interfaces

* Support 1:1 protection for SW (core card) card

* Support 1588V2 and Synchronous Ethernet

* Support embedded OTDR in SFP

The ZXA10 C320 is industry’s first compact design PON OLT that is widely used in low-density, outdoor deployment and limited space scenarios.

Features
Compact design
2U high with 2 service card slots, the service card is same as ZXA10 C300. It helps save room space greatly, especially suitable for suburban district, enterprises and rural areas.
Unified platform architecture
The ZXA10 C320 is a unified platform that integrates GPON/EPON, 10G PON (XG-PON1/XGS-PON/10G EPON) as well as PtP. It supports on-demand deployment, flexible access, and ensures sustainable network evolution.
Flexible networking

Supports FTTH, FTTO, FTTdp, FTTB, FTTV and FTTM, and enhances the networking ability when deploying together with ZXA10 C300.
Higher reliability and protection
Provides boards redundancy and hot swappable, supports type B and type C protection for PON downlink and RSTP/ERPS/UAPS/LACP for uplink.
Perfect clock/time synchronization
Supports synchronous Ethernet, BITS, 1PPS+ToD and 1588V2 to meet the network and service requirements for mobile backhaul.
Powerful QoS control and E-OAM
Supports H-QoS based on service provider, user and service, and provides E-OAM functions for efficient network management.
Integrated outdoor cabinet supports extensive deployment
Supports AC, DC and backup power supply as well as a wide range of outdoor cabinets as per customer demands, allowing the deployment in extreme environments such as high mountains, deserts, rainforests, and islands.
Eco-friendly design
Supports multiple ways to lower the power consumption and complies with the international standards and requirements, such as CoC.

Specification:

System Architecture

Capacity

GPON up to 32 ports
Uplink interfaces up to 4 *GE (Optical )+2*GE(Electronic) or 2*10GE(Optical )+2*GE(Optical ) +2*GE(Electronic)

Chassis Configuration (19”)

Total 5 slots
2 slots for universal line cards
2 slots for switch& control cards
1 slot for fan module

Subscriber Card Density

GPON card: 8/16 ports per card
XG-PON1 card: 8 ports per card
P2Pcard: 24/48 ports per card

Uplink interface card

1*10GE optical port ( Configurable 1*GE optical port)
1*GE optical port
1*10 M/100 M/1000 M electrical Ethernet port

Common interfaces

1*environment detecting interface
1*management interface
1*maintenance serial interface

PON Features

GPON compliant with ITU G.984.x

P2P compliant with ITU G.985/G.986
XG-PON1 compliant with ITU G.987.x and G.988
Support 1:128 optical split ratio for xPON
Support OLS (Optical Laser Supervising )
Max logical reach: 60km
Max physical reach: 20km
Max link difference: 20km
High-efficient DBA: NSR-DBA,SR-DBA


Synchronous Ethernet
GPON Transceiver power: Class B+ or class C+
XG PON1 Transceiver power: Class N1 and N2a
Type B and type C optical uplink protection
Support FEC
Support AES128
Support SCB
GPON MCM(Multi-Copy Multicast)
Support 1550nm for third party CATV broadcasting

L2/L3Features
4K VLAN
1:1/N:1 VLAN
802.1ad, SVLAN, Selective QinQ, VLAN stacking
Line-speed forwarding
STP/RSTP/MSTP compliant with IEEE 802.1d/802.1w/802.1s
Link aggregation IEEE 802.3ad
DHCP server, DHCP Relay (option 60/82), DHCP proxy
IPv4/IPv6 dual stack

L3 routing:
12K IPv4 routing forwarding entries
IPv4 and IPv6 statistic routing
Multicast –IPTV
1K Multicast groups
IGMP Snooping and proxy (v1/v2/3)
MLD V1/ V2,snooping/proxy
MVLAN: 256
Channel Access Control (CAC), Preview (PRV) and Call Detail Record (CDR) for IPTV
Less than 50ms channel zapping delay

QoS
8 queues per port
Queue & scheduling mechanism: SP, DWRR, SP+DWRR
DSCP labeling and relabeling
Stream classification, rate limiting, shaping and priority setting
Traffic statistics
Service based rate limit
WRED and triple color
SLA: CIR, PIR, EIR

Security
L2-L4 ACL
IP and MAC source guard
Resistance against DOS attacks
MAC/IP anti-spoofing (MAC binding, IP binding, DHCP snooping)
Anti-flooding: broadcast packet suppression, IGMP packet suppression, DHCP packet suppression
MAC address number limit based on VLAN or GEM-port or xGEM-port

Port mirroring
User port identification such as PPPOE+ and DHCP Option 82

Environment
Operating temperature: -40 ºC ~ +65 ºC
Operating humidity: 5% ~ 95%, non-condensing

PowerSupply
Working voltage: -48 V (±20%) or: -60 V (±20%)
AC: 100V~240V

Dimensions
86.1mm (H)* 482.6mm (W)* 270mm (D)(19 inch shelf)
2200 mm (H)x600 mm (W)x300 mm ((D) (Rack)
1035 mm(H) x 770 mm(W) x 460 mm(D) (Outdoor Cabinet)
