ZXA10 C300, the world's first future-proof and largest capability optical access platform, is developed with mass optical access roll-out as well as economy in mind. Its powerful functions and high performance make mass FTTx roll-out easier than ever before.

        ZXA10 C300 is big OLT equipment with high density, high bandwidth and scalable office end equipment of passive optical access. It supports all kinds of FTTx application modes.

       Addressing all types of FTTx network requirements with the most appropriate

technology, ZTE launched ZXA10 C300, world's first unified platform supporting GPON, EPON and P2P as well as the emerging next generation IEEE 10GEPON and FSAN/ITU-T NG-PON in one platform.

PON Features

• EPON compliant with IEEE 802.3ah
• GPON compliant with ITU G.984.x
• 10GEPON compliant with IEEE 802.3v
• Support up to 1:128 optical split ratio for GPON,1:64 optical split ratio for EPON and 1:256 optical split ratio for 10GEPON
• Support OLS (Optical Laser Supervising )
• Physical reach: 20~60km
• Highly-efficient DBA: NSR-DBA,SR-DBA
• 1PPS+TOD,IEEE 1588V2
• Transceiver power: Class B+ or class C+
• Type B and type C optical link protection
• FEC
• AES128
• SCB

Features

• 1:1/N:1 VLAN
• 802.1ad, SVLAN, Selective QinQ, VLAN stacking
• Line-speed forwarding
• STP/RSTP/MSTP compliant with IEEE 802.1d/802.1w/802.1s
• Link aggregation IEEE 802.3ad
• DHCP server, DHCP Relay (option 60/82), DHCP proxy
• L3 routing:
• RMON II
• Multicast – IPTV
• QoS
• Queue & scheduling mechanism: SP, DWRR, SP+DWRR
• IPv4 DSCP Diffserv
• Stream classification, rate limiting, shaping and priority setting

Dimensions

449.2mm (H) * 535mm (W) * 270mm (D) (21 inch shelf)

443.7mm (H) * 482.6mm (W) * 270mm (D) (19 inch shelf)

2200 mm (H) x 600 mm (W) x 300 mm ((D) (Rack)

Weight

60kg (Empty rack for 19inch and 21 inch)

175kg  (19 inch rack)

183kg (21 inch Rack)

Return Material Authorization (RMA) Process

Standard Hardware Warranty Policy:

Original new sealed ZTE product: 1 Year

The Support Contacts:

If your ZTE products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.

Cargo will be delivered within 1 day after payment arrived. Tracking Number will be offered once delivery done.
