H902MPLA Board Description
The H902MPLA board is a control board. It is the core of the system control and service switching and aggregation. The H902MPLA board can also function as the management and control core of the integrated network management system (NMS). It communicates with service boards about the key management and control information through the master/slave serial port and inband GE/10GE channel. In this manner, the H902MPLA board configures, manages, and controls the device, and also implements the simple route protocol functions.
Feature and Specifications
Please refer to "Comparison Between Boards of the Same Type".
Parameters
Please refer to "Power Consumption and Maximum Frame Size of Boards".
Working Principle
Figure 1 Working principle of the H902MPLA board
| | Indicates the channel of control signal. | | Indicates the channel of service signal. |
| | Control module: manages the entire board and the service boards, and communicates with the fan tray through the extended serial port. | | Service processing module: Providing four GE/10GE ports for upstream transmission using ports on the front panel. Providing four 10GE ports for load sharing with the standby control board. Switching module: switches services at Layer 2 or Layer 3, and provides 17 50G channels for implementing service switching on each service board or upstream board. |
| | Indicates the channel of power or clock signal. | | The power module supplies power to each functional module of the board. The clock module provides clock signals for each functional module of the board. |
Front Panel Port
For details about supported optical module, see 10GE Optical Module and GE Optical/Electrical Module.
NOTE:
Default transmission rate of the upstream port or cascade port is 10000 Mbit/s (10GE), which can be set to 1000 Mbit/s (GE) by running the speed command.
Daughter Board
The H902MPLA board can be configured with a matching daughter board. Figure 2 shows the position of the daughter board on the H902MPLA board.
For details about the daughter board and functions supports by the H902MPLA board, see Daughter Board.
Figure 2 Position of the daughter board on the H902MPLA board
| 02315925 | Function module,ONUF01D500,H37M2HEU,Heat Exchanger,Temperature control unit,HX03T-22SH | Heat Exchanger | Outdoor |
| 04041570 | Single Cable,Storage Battery -48V Feeder Cable,0.3m,PP75BL,2*10UL1015BL,OT10-6,HONET | Cable heat exchanger | Outdoor |
| 02350RQA | ETP4890 Power Supply Unit | ETP4890 | |
| 34100080 | Optical Functional Module,1000BASE-T-SFP Module,RJ45 Electrical Module,Auto Negotiate,Longest Transimission Distance 100m | E-SFP | Testing |
| 03038673 | HONET P3,H601TSSB0,Test System of Subscriber | H601TSSB0 | Test Board |
| 03025KET | Manufactured Board,MA5800,H902PILA,Connect Power Board,1*3 | H902PILA | MA5800-X17 |
| 03025KFE | Main Processing Board MPLA | H903MPLA | MA5800-X17 |
| 03025KFF | Manufactured Board,H902MPLB | H902MPLB | MA5800-X17 |
| 03033DMT | 16-port Advanced XGS-PON OLT Interface Board | H902XSHF | MA5800-X17 |
| 03025KEW | 16-port Advanced XGS-PON & GPON Combo OLT Interface Board | H902CSHF | MA5800-X17 |
| 02312MAM | Function Module,MA5800,H902CSHF,16-port Advanced XGS-PON & GPON Combo OLT Interface Board(including B+ SFP+ Optical Module),(03025KEW+16*34061718) | H902CSHF01 | MA5800-X17 |
| 03033DPA | Finished Board,MA5800,H902FLHF,16-port Advanced Flex-PON2.0 OLT Interface Board | H902FLHF | MA5800-X17 |
| 03026SGN | 48-port Advanced GE/FE Optical Interface Board | H902OGHK | MA5800-X17 |
| 03025KFB | 8-port Enhanced 10GE Uplink Interface Board | H902NXED01 | MA5800-X17 |
| 03033DPC | 8-port Advanced 10GE Optical Interface Board | H902OXHD | MA5800-X17 |
| 02114461 | 2.2m Front-access ETSI Assembly Cabinet(-48V) | H90B1N63E Cabinet | MA5800-X17 |
| 02115877 | Assembly Cabinet,MA5800,H90B8N63E,2.2m ETSI Cabinet(DPD60-4-4B,Containing 1 Subrack,Maximum 2 Subracks) | H90B8N63E Cabinet+Shelf+PDU | MA5800-X17 |
| 02122394 | Power Distribution Box,SmartAX MA5800,DPD60-4-4C,-48V,1PH,60A,4,4*60A,DC-4input&4output Nader breaker | DPD60-4-4C Cabinet's PDU | MA5800-X17 |
| 02352JSH | Assembling Components,MA5800-X17,H90Z5BPLB,MA5800 ETSI Service Shelf, 8-fan AI 1.0 | H90Z5BPLB Cabinet's Shelf | MA5800-X17 |
| 14130396 | Patch Cord,LC/UPC,LSH/APC,Single-mode,20m,G.652D,2mm,LSZH | SS-OP-LSH-LC-S-20 Patch Cord | MA5800-X17 |
| 14135475-002 | Patch Cord,LSH/APC,SC/UPC,Single-mode,15m,G.652D,2mm,LSZH | SS-OP-LSH-SC-S-15 Patch Cord | MA5800-X17 |
| 25030101 | Power Cable,450V/750V,60227 IEC 02(RV),25mm^2,Blue,112A,CCC,CE (Unit:meter) | C1025BL00 Power cable | MA5800-X17 |
| 25030433 | Power Cable,450V/750V,60227 IEC 02(RV),25mm^2,Red,112A,CCC,CE (Unit:meter) | C1025RE00 Power cable | MA5800-X17 |
| 25030431 | Power Cable,450V/750V,60227 IEC 02(RV),25mm^2,Yellow/Green,112A,CCC,CE (Unit:meter) | C1025YG00 Power cable | MA5800-X17 |
| 34061971 | PON Transceiver,SFP+,1577nm(TX)/1270nm(RX),9.953G(TX)/9.953G(RX1)/2.488G(RX2),2dBm,5dBm,-26dBm/-27.5dBm,SC/UPC Compatible with SC/PC,SM,XGS-PON OLT N1 | SFP | MA5800-X17 |
| 34061968 | PON Transceiver,SFP+,1577nm(TX)/1270nm(RX),9.953G(TX)/9.953G(RX1)/2.488G(RX2),4dBm,7dBm,-28dBm/-29.5dBm,SC/UPC Compatible with SC/PC,SM,XGS-PON OLT N2 | SFP | MA5800-X17 |
| 34061718 | PON Transceiver,SFP+,1577nm(TX1)/1490nm(TX2)/1270nm(RX1)/1310nm(RX2),9.953G(TX1)/2.488G(TX2)/9.953G(RX1)/2.488G(RX2)/1.244G(RX3),1dBm/1.5dBm,6dBm/5dBm,-25dBm/-26.5dBm/-28dBm,SC/UPC Compatible with SC/PC,SM,XGS-PON&GPON OLT B+ | SFP | MA5800-X17 |
| 34061720 | PON Transceiver,SFP+,1577nm(TX1)/1490nm(TX2)/1270nm(RX1)/1310nm(RX2),9.953G(TX1)/2.488G(TX2)/9.953G(RX1)/2.488G(RX2)/1.244G(RX3),5dBm/3dBm,8dBm/7dBm,-29dBm/-30.5dBm/-32dBm,SC/UPC Compatible with SC/PC,SM,XGS-PON&GPON OLT C+ | SFP | MA5800-X17 |
| 21138396 | Blank Panel for GPIO Slot (Shielded) | H80XBPGPIO01 Shelf's Blank Panel | MA5800-X17 |
