Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | MA5616 |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| Type: | OLT, MA5616 | Product Name: | DSLAM |
|---|---|---|---|
| SKYPE: | Poppylee7 | Port: | Shenzhen |
Huawei FTTx+DSL MA5616 IP DSLAM
The MA5616 is an industry-leading remote PON multi-dwelling unit (MDU) with a plug-in design. It has the following features: high access density, superior processing performance, high reliability, easy maintenance, energy saving, and future-oriented architecture design. The device provides ADSL2+, VDSL2, SHDSL, POTS, FE, P2P, ISDN, and Combo user ports, and supports dual upstream transmission channels through auto-negotiation GPON/EPON/GE ports at the network side. It can be smoothly upgraded to support 10G PON. The MA5616 can be used as a mini-DSLAM/mini-MSAN in FTTC/FTTB scenarios. It can be deployed indoors, for example, on a corridor wall or outdoors, for example, in an outdoor cabinet to provide high-bandwidth, flexible density, and multi-scenario service coverage for multi-resident buildings and small and medium-sized enterprises (SMEs).
| 02351510 | Multi-service Access Equipment Host Assembly Components | mini MSAN frame | MA5616 |
| 03020PPS | Centralized Control Unit Board | CCUB | MA5616 |
| 03020MKT | GE Interface Card | H831GE1A | MA5616 |
| 03020LWA | Analog Subscriber DSP Card | H836ASDA | MA5616 |
| 03020MCM | 32-Channel ADSL2+ Board(with 600 ohm Splitter) | H835ADLE | MA5616 |
| 03020MCT | 16-port VDSL over POTS Service Board(with 600 ohm Impedance Splitter) | H835VDGE | MA5616 |
| 03020PFJ | 24-port VDSL2 over POTS Service Board(with 600 ohm Impedance Splitter) | H835VDSE | MA5616 |
| 03021TNT | H83BVCLE - 32-Channel VDSL2 over POTS vectoring. Built in spiltter (021ETG H83BVDLE /H830D00VDLE01 ) | H83BVCLE | MA5616 |
| 03020MWT | 64port POTS Subscriber Board | H838ASPB | MA5616 |
| 03020PXY | 16-port SHDSL Service Board | H832SHLH | MA5616 |
| 03020QXV | 8-port ISDN Digital Subscriber Card | H832DSLD | MA5616 |
| 03030KRG | AC Power Board, Power Backup | H831PAIB | MA5616 |
| 03030QWY | MA5616,H831PAIB1,AC Power board,Power Backup | H831PAIB1 | MA5616 |
| 03020CKS | DC Power Input Unit | H831PDIA | MA5616 |
| 03021SXV | H832PDVAA - Power Board | H832PDVAA | MA5616 |
| 03021PVH | H831CCUE - Centralized Control Unit Board | H831CCUE | MA5616 |
| 03020VSC | MA5616,H832PDIA,Dual DC Power Input Unit,1*1 (H831PDIA) | H832PDIA | Cancel |
Contact Person: Mr. Leo yang
Tel: +86 15684227158
