Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | OLT |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| Product Name: | MA5818 | Application: | FTTX Network |
|---|---|---|---|
| Warranty: | 1 Year | Power Supply: | 220V |
| Port: | Shenzhen |
As a multi-service access device, the MA5818 supports ultra-broadband access and flexible capacity expansion. It provides G.fast, SuperVector, Vectoring, VDSL2, and POTS user ports and can be used in fiber to the building (FTTB) and fiber to the curb (FTTC) scenarios that demand high bandwidth access.
Ultra-High Bandwidth
• Pioneers the use of G.fast and SuperVector, which are innovative high-bandwidth access technologies that use wider spectrums to meet high bandwidth requirements on copper lines.
• G.fast allows operators to define upstream and downstream rates, and use existing copper resources to support new services such as HD video, remote home surveillance, and city surveillance.
Flexible Capacity Expansion
• Provides separate VP slots to support smooth capacity expansion.
• Adopts the innovative G.fast board-insertion design, enabling on-demand G.fast deployment.
Fast deployment
• Maximizes the use of existing copper resources to meet future bandwidth demands and avoid the difficulty of routing fibers to homes.
• G.fast is compatible with VDSL2, allowing live-network users to be smoothly upgraded. Moreover, G.fast lines consume less power than VDSL2 lines.
Easy Maintenance and Management
• Supports remote software commissioning, offline deployment, and plug and play (PnP).
• Supports remote fault locating, troubleshooting, and batch upgrade.
• Supports mature FTTx network management modes, and allows G.fast lines to be diagnosed and tested as xDSL lines.
| MA5818 | MA5821 | MA5822 | MA5898 |
| 482.6mm×245mm×88.1mm | MA5821 8FE | 442mm×220mm×43.6mm | 442mm×220mm×43.6mm |
| 250mm×180mm×43.6mm | |||
| MA5821 16FE/24FE | |||
| 442mm×220mm×43.6mm | |||
| .-40℃~+65℃ | .-40℃~+65℃ | .-40℃~+65℃ | .-40℃~+65℃ |
| 5%~95% | 5%~95% | 5%~95% | 5%~95% |
| DC: -38.4V~-72V | AC:220V | AC:220V | 220V(AC)+(2V DC) |
| 90V~264V AC | DC:-48V | ||
| .-43.2V~-52V DC | |||
| 1 pots SFP | 1 pots SFP | 1 pots SFP | 1 pots SFP |
| 10G PON or PON | 10G PON or PON | 10G PON or PON | 10G PON or PON |
| 4 SET | 8FE | 8FE+8POTS | 4GE+8FE |
| support 20 type | 16FE | 16FE+16POTS | 4GE+8E1 |
| support pots: | 24FE | 24FE+24POTS | 2GE(E)+2GE(O)+8FE |
| GE,FE,ADSL2+VDSL2,POTS | 2GE(E)+2GE(O)+8E1 | ||
| 8a,8b,8c,8d,12a,12b,17a | |||
| 6KV;DSL/POTS/ISDN:4KV | 6kv | 6KV; | 6KV; |
| FE:6KV; | FE:6KV | FE:6KV | |
| POTS:4KV |
ASRB:32*POTS ; ASPB:64*POTS
DSLD:8*ISDN
ADLE:32*ADSL2+ ;ADPE:64*ADSL2+
CALE:32*ADSL2+ +32*POTS
CVLC/CVLE:32VDSL2+32POTS
CCME:48VDSL2+48POTS
EIUA:16*FE ;EIUD:4GE+4FE
VCLE/VCLF:32*VDSL2,Vectoring
VCPE/VCPD:64*VDSL2,8a,8b,8c,8d,12a,12b,17a
VDGE:16*VDSL2,8a,8b,8c,8d,12a,12b,17a,30a
VDSH:24*VDSL2,8a,8b,8c,8d,12a,12b,17a
VDTH: 24*VDSL2(ISDN),8a,8b,8c,8d,12a,12b,17a
VDSE: 24*VDSL2(ISDN),8a,8b,8c,8d,12a,12b,17a
VDLE:32*VDSL2(POTS),8a,8b,8c,8d,12a,12b,17a
VDLF:32*VDSL2(POTS),8a,8b,8c,8d,12a,12b,17a
VDMM/VCMM:48*VDSL2,8a,8b,8c,8d,12a,12b,17a
SDMM: 48*VDSL2,8a,8b,8c,8d,12a,12b,17a,35b
SHLH:16*SHDSL,ATM SHDHL ,EFM SHDHL
EDTB: 8G.SHDSL +8E1
Return Material Authorization (RMA) Process
Standard Hardware Warranty Policy:
Original new sealed ZTE product: 1 Year
The Support Contacts:
If your ZTE products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.
Cargo will be delivered within 1 day after payment arrived. Tracking Number will be offered once delivery done.
Uonel is one of the biggest Huawei Network Hardware distributor in china, founded in 2008. We are a global provider of netwotking products with more than 5000 customers.
We provide original new Huawei Routers,Switches,Firewalls,Wireless APs & controllers,OLTs,GPON modems,optical transceivers.Our company have more than $5million Huawei products in stock.
Most of our technical engineers had work exprience in Huawei company,we can provide network design&planning,configration,troubleshooting,maintenance and training service in world wide.
Contact Person: Mr. Leo yang
Tel: +86 15684227158
