Shenzhen Uonel Technology Co., Ltd. is a Global Provider of Telecommunication Equipment and Services.
 |
| Place of Origin: | China |
| Brand Name: | Huawei |
| Certification: | CE FCC RoHS |
| Model Number: | OLT |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export carton package |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 Piece/Pieces per Week |
| Product Name: | MPSA | Application: | FTTH FTTB FTTX Network |
|---|---|---|---|
| Type: | MA5800 X2 | Warranty: | 1 Year |
| Skype: | Poppylee7 | Port: | Shenzhen |
H901MPSA Board Description
The H901MPSA board is a control board. It is the core of the system control and service switching and aggregation. The H901MPSA board can also function as the management and control core of the integrated network management system (NMS). It is applicable to the MA5800-X2 service subrack. It exchanges the key management and control information with service boards through the master/slave serial port and in-band channel. In this manner, the H901MPSA board configures, manages, and controls the device, and also provides simple dynamic routing
Board Specifications | H901MPLA | H902MPLA | H903MPLA | H901MPLB | H902MPLB | H901MPSC | H901MPSA |
|---|---|---|---|---|---|---|---|
Bandwidth per slot (load balancing mode) | 100 Gbit/s | 100 Gbit/s | 100 Gbit/s | 200 Gbit/s | 200 Gbit/s | 80 Gbit/s | 40 Gbit/s |
Upstream or cascading port | 4 x 10GE/GE ports | 4 x 10GE/GE ports | 4 x 10GE/GE ports | 4 x 10GE/GE ports | 4 x 10GE/GE ports | 4 x 10GE/GE ports |
|
ALM port | No | No | No | No | No | Yes (7 Boolean value inputs and 1 Boolean value output) | Yes (7 Boolean value inputs and 1 Boolean value output) |
BITS/TOD port | No | No | No | No | No | Yes (1 external clock/time input and output) | Yes (1 external clock/time input and output) |
MAC address table size | 262143 | 262143 | 262143 | 262143 | 262143 | 262143 | 262143 |
Access ONTs | 17408 | 17408 | 17408 | 17408 | 17408 | 4096 | 4096 |
Multicast users | 17408 | 17408 | 17408 | 17408 | 17408 | 4096 | 4096 |
Static programs |
| 8192 | 8192 |
| 8192 | 8192 (V100R017C10 and later versions) | 8192 |
Online programs | V100R016C00: 4000 V100R016C10:
V100R017C10 and later versions:
|
|
| V100R016C00: 4000 V100R016C10:
V100R017C10 and later versions:
|
| V100R017C10 and later versions:
|
|
IPv4 routing table size | 65536 | 65536 | 65536 | 65536 | 65536 | 65536 | 65536 |
IPv6 routing table size | 16384 | 16384 | 16384 | 16384 | 16384 | 16384 | 16384 |
Return Material Authorization (RMA) Process
Standard Hardware Warranty Policy:
Original new sealed ZTE product: 1 Year
The Support Contacts:
If your ZTE products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.
Cargo will be delivered within 1 day after payment arrived. Tracking Number will be offered once delivery done.
Uonel is one of the biggest Huawei Network Hardware distributor in china, founded in 2008. We are a global provider of netwotking products with more than 5000 customers.
We provide original new Huawei Routers,Switches,Firewalls,Wireless APs & controllers,OLTs,GPON modems,optical transceivers.Our company have more than $5million Huawei products in stock.
Most of our technical engineers had work exprience in Huawei company,we can provide network design&planning,configration,troubleshooting,maintenance and training service in world wide.
Contact Person: Mr. Leo yang
Tel: +86 15684227158
