Huawei CSHF 16-Port XGS-PON And GPON Combo OLT Interface Board H901CSHF h901twed xgspon ,huawei ma5800 h901xsed,h902cshf,h901xgs

XEBD XGBD XHBD GPSF EPHF XEHD EDSH

H901CGID Board Description

The H901CGID board is an 8-port XG-PON and GPON Combo OLT interface board. It works together with the optical network unit (ONU) to provide XG-PON and GPON access services.

 H901CGID     H901CGUD     H901CGHF     H901CGUF     H90CSHF     H902CGHD     H902CSHD

Parameters

Board Parameter

You can query power consumption, weight, maximum frame size, and normal operating temperature of all boards.

Table 1 lists the power consumption, weight, and maximum frame size of boards.

The operating temperature of H901XSED and H901TWED is -40°C to +55°C (in MA5800–X17/X15/X7) or -40°C to +65°C (in MA5800–X2) and the lowest board startup temperature is -25°C. The operating temperature of other boards is -40°C to +65°C and the lowest board startup temperature is -25°C.

 NOTE:

The power consumption of a board is calculated based on the following conditions:

Operating voltage: -53.5 V DC.

Ambient temperature: 25°C.

Static power consumption: All ports do not carry any loads and optical modules are not installed on optical ports.

Maximum power consumption: All ports fully carry loads.

The board power consumption slightly varies with the power module configured for the board and discreteness of components.

Table 1 Power consumption and maximum frame size of boards

Return Material Authorization (RMA) Process

Standard Hardware Warranty Policy:

Original new sealed ZTE product: 1 Year

The Support Contacts:

If your ZTE products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.

Cargo will be delivered within 1 day after payment arrived. Tracking Number will be offered once delivery done.
